Поз.
Артикул
Описание
7
AIR CLEANER LESS BRACKET
14
FILTER ELEMENTTO 394 094 70 01
21
SEPARATORTO 341 094 70 02,341 094 74 01
28
CARTRIDGE
35
DUST COLLECTOR BOWLTO 341 094 70 02,341 094 74 01
42
NUTTO 341 094 70 02,341 094 74 01
49
SPRING CLIPTO 341 094 70 02,341 094 74 01
56
FASTENERTO 341 094 70 02,341 094 74 01
63
BRACKET AIR CLEANER
70
VACUUM BOX
70
SWITCH
77
COVER
77
COVER
84
SCREW EXHAUST PIPE TO BRACKET
84
SCREW WATER SEPARATOR
91
LOCK WASHER BRACKET TO TRANSMISSION CASE,5 537500
98
NUT BRACKET TO FRAME
105
HOSE FROM PICO AIR CLEANER TO TURBOCHARGER
112
AIR INTAKE PIPE
119
HOSE
119
HOSE
168
LOOM TIE80-95 MM
168
CLAMP AS REQUIRED
168
LOOM TIE INTAKE AIR LINE
175
CLAMP
175
LOOM TIE
175
CLAMP100-120
