3231 K - 3248 K - 932.307 - 47 FUEL SYSTEM
Поз.
Артикул
Описание
15
FUEL TANK RIGHT 300L
15
FUEL TANK TO BE MOUNTED ON THE LEFT 300 L, UP TO: 04.98
30
SCREW PLUG FUEL DISCHARGE
45
SEALING RING. SEAL RING FUEL TANK
60
SUPPORT FUEL TANK TO FRAME
60
SUPPORT FUEL TANK TO FRAME
70
SUPPORT REAR TANK
105
STRAP FUEL TANK TO CONSOLE
120
PIN STRAP TO SUPPORT
135
CLIP RESERVOIR TO CAB FRONT PANEL
140
CLIP STRAP TO SUPPORT
150
NUT STRAP TO SUPPORT M12X1.5
165
PAD STRAP 61 MM
180
PAD BRAKE ANCHOR 35.9MM
180
PAD BRAKE ANCHOR 53 MM
