Поз.
Артикул
Описание
71
72
73
74
77
NUT BATTERY,XB209706
77
NUT HORN TO BRACKET M8
78
79
80
81
82
SCREW CLAMP ON BRACKET
83
WASHER BRACKET TO LEFT SIDE MEMBER
83
WASHER BRACKET TO CAB REAR PANEL
84
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
85
HEXAGON HEAD BOLT CLAMP AT SUPPORTING RAIL M 8X30
89
89
89
95
SCREW BRACKET TO SIDE MEMBER M8X20
95
SCREW BRACKET TO CAB REAR PANEL M 8X20
101
NUT ENGINE MOUNTING M8
107
107
110
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
110
SCREW , Replaced By: N910143008002
113
HEXAGON HEAD BOLT BRACKET TO BRACKET M10X35
113
SCREW BRACKET TO SIDE MEMBER M10X35
116
NUT HORN TO BRACKET M8
119
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
185
191
191
203
BOLT BRACKET BELT TENSIONER AND GENERATOR TO OIL PAN M8X190
203
SCREW SOLENOID VALVE TO BRACKET M 8X180
203
SCREW 3/2-WAY VALVE TO BRACKET
218
SCREW BRACKET TO SIDE MEMBER M8X20
218
SCREW BRACKET TO CAB REAR PANEL M 8X20
224
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
224
HEXALOBULAR BOLT CLAMP ON BRACKET M6X30
999
SCREW BUMPER TO REAR CROSS MEMBER M 8X50
999
HEXAGON HEAD BOLT. SCREW ON STOP M 8X50
