Поз.
Артикул
Описание
5
STIFFENING FRONT RIGHT
5
STIFFENING LEFT
8
REPAIR KIT FRONT BUMPER
11
SCREW , Replaced By: N304017008016
11
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
14
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
14
SPRING WASHER , Replaced By: N000137008212
17
NUT , Replaced By: N304032008006
17
NUT
20
BUMPER JOINT COVER
23
RAIL , FROM CHASSIS 023 008964 024 004277 043 010984 044 015234
26
CLIP , FROM CHASSIS 023 008964 024 004277 043 010984 044 015234
35
FRONT BUMPER FACE BAR LEFT, FROM CHASSIS 022 000730 023 010008 024 008419 042 000096 043 011674 044 022301
35
FRONT BUMPER FACE BAR RIGHT, FROM CHASSIS 022 000730 023 010008 024 008419 042 000096 043 011674 044 022301
38
SHEET METAL SCREW BRACKET TO CAB FLOOR
41
SPRING WASHER ALTERNATOR CONNECTION D+
44
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
44
SCREW , Replaced By: N304017008016
47
NUT , Replaced By: N304032008006
47
NUT
50
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
50
SPRING WASHER , Replaced By: N000137008212
53
PLUGTO 123 880 12 70
56
RAIL RIGHT
56
RAIL LEFT
59
NUT
59
NUT , Replaced By: N304032008006
62
SPRING WASHER , Replaced By: N000137008212
62
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
65
NUT BALL PIVOT TO LEVER
68
WASHER , Replaced By: N009021008213
68
WASHER BRACKET TO LEFT SIDE MEMBER
71
BUMPER JOINT COVER
74
SCREW BRACKET TO FENDER,K 104588
77
NUT
77
NUT , Replaced By: N304032008006
80
SPRING WASHER , Replaced By: N000137008212
80
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
83
BRACKET LEFT, FROM CHASSIS 043 003651
83
BRACKET , Replaced By: A1078850940
83
BRACKET , Replaced By: A1078851040
83
BRACKET RIGHT, FROM CHASSIS 043 003651
86
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
89
WASHER BRACKET TO BRACKET
92
BRACKET LEFT
92
BRACKET RIGHT
95
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
98
WASHER , Replaced By: N000125010532
98
WASHER RADIATOR TO RUBBER MOUNTING
101
WASHER BRACKET TO COVERING
101
WASHER , Replaced By: N009021010209
104
LICENSE PLATE MOULDING FRONT
107
BRACKET
110
SCREW , Replaced By: N304017008039
110
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
113
SPRING WASHER , Replaced By: N000137008212
113
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
116
SCREW CONTROL UNIT TO CAB
116
SCREW ELECTRIC CABLE TO PIPE BEND
119
WASHER , Replaced By: N009021005205
119
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
122
NUT TACHOGRAPH TO BRACKET
125
SPOILER FRONT, TO BE PAINTED PRIOR TO INSTALLATION
128
TAPPING SCREW. SHEET METAL SCREW FUEL LINE
131
WASHER , Replaced By: N009021004207
131
WASHER COVERING TO CYCLONE AIR TRAP
134
NUT BALL PIVOT TO LEVER
137
WASHER
140
SCREW BUMPER TO WHEELHOUSE ANGLE
