Поз.
Артикул
Описание
5
CABLE HARNESS TAIL LAMP CABLE HARNESS
5
CABLE HARNESS TAIL LAMP CABLE HARNESS
5
CABLE HARNESS , Replaced By: A1075403507
8
PIN BUSHING HOUSING , 10/20 UP TO CHASSIS 4 411810,50/60 UP TO CHASSIS 4 414810
11
COVER , 10/20 UP TO CHASSIS 4 411810,50/60 UP TO CHASSIS 4 414810
14
PIN BUSHING HOUSING 4-POLE, UP TO CHASSIS: 114.005,007,008,015,017 049721 114.010 044486 114.021 003371 114.022 007377 114.023 001704 FROM CHASSIS SEE 10948
14
PLUG TRIPLE
17
COVERTO 007 545 00 28
20
PIN BUSHING HOUSING SEAT HEATER RELAY, 8-POLE
23
COVERTO 006 545 81 28
26
ROUND PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
26
ROUND PIN BUSHING , Replaced By: A0035452626
29
PIN BUSHING HOUSING 4-POLE
32
PIN BUSHING HOUSING LAMP CONTROL
35
ROUND PIN BUSHING2.5 MM2
35
PIN BUSHING , Replaced By: A0025459926
38
PLUG HOUSING FINAL CONTROL ELEMENT, 8-POLE
41
PLUG PIN ADDITIONAL CABLE TO SERIES CABLE
44
PIN BUSHING RADIO SET
47
INSULATING SLEEVETO 000 546 43 40
50
GROMMET ENGINE COMPARTMENT LAMP
53
GROMMET
56
BRACKET COUPLER
59
SHEET METAL SCREW BRACKET TO CAB FLOOR
62
SCREW TAIL LAMP GROUND CABLE TO WHEEL ARCH PANEL
65
LOCK WASHER T-FITTING TO BRACKET
68
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
71
CLIP TAIL LAMP CABLE HARNESS TO REAR LID
71
CLIP LINE MOUNTING
74
CLIP FUEL LINE TO CAB CONSOLE
77
CLAMP ELECTRIC CABLE TO BRACKET
77
CLAMP CABLE HARNESS TO TAIL CENTRAL PIECE
80
SHEET METAL SCREW , Replaced By: N000000002062
80
SCREW
83
GROMMET
83
GROMMET CAB ROOF
86
CLIP FUEL LINE TO CAB CONSOLE
89
GROMMET LICENSE PLATE LAMPS TO TAIL CENTRAL PART
92
GROMMET COMBINED TAIL LAMP CABLE HARNESS THRU REAR PANEL
92
GROMMET
