Поз.
Артикул
Описание
101
LEVER
102
DETENT
103
WASHER COMPRESSED AIR LINE TO BRACKET
103
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
104
LOCK PLATE
105
NUT BALL PIVOT TO LEVER
106
SHIFTING FORK
107
LINKAGE
108
BALL SOCKET
109
NUT , NO LONGER AVAILABLE
110
SECURING CLIP. CIRCLIP
170
CASE COVER LESS GOVERNOR, PUMP, AND DRIVE GEAR, NO LONGER AVAILABLE
171
PISTON , NOT INCLUDED IN RANGE OF DELIVERY 112 270 11 16
172
SPRING , NOT INCLUDED IN RANGE OF DELIVERY 112 270 11 16
173
SPRING OUTSIDE, NO LONGER AVAILABLE
174
SPACER WASHER MAXIMUM,4 PIECES, NOT INCLUDED IN RANGE OF DELIVERY 112 270 11 16
175
PISTON , NOT INCLUDED IN RANGE OF DELIVERY 112 270 11 16
176
SPRING , NOT INCLUDED IN RANGE OF DELIVERY 112 270 11 16
177
SPACER WASHER MAXIMUM,2 PIECES, NO LONGER AVAILABLE
178
GASKET , Replaced By: A1122771680
178
GASKET
179
LOCKING SHEET
180
SCREW STEERING COLUMN PANELLING M 5X12
181
SPRING WASHER AT GENERATOR TERMINAL D+, 010,10/50 UP TO CHASSIS 066175,010,12/52 UP TO CHASSIS 067208 EXCEPT FOR 067205,010,20/60 UP TO CHASSIS 065672,010,22/62 UP TOCHASSIS 068683 012,10/50 UP TO CHASSIS 151591 EXCEPT FOR,SEE FOOTNOTE 074,012,12/52 UP TO CHASSIS 153776 EXCEPT FOR 153758,153760,153771 012,20/60 UP TO CHASSIS 148879 EXCEPT FOR 148827,148837,148844,148850,148852,012,22/62 UP TO CHASSIS 158113
182
DRIVE SHAFT , 015 FROM TRANSMISSION 005208 NOT INCLUDED IN RANGE OF DELIVERY 112 270 11 16
183
SEAL RING
184
PIN REPAIR SIZE 5.4 MM, NOT INCLUDED IN RANGE OF DELIVERY 112 270 11 16
185
BUSHING , NO LONGER AVAILABLE
186
SPRING
187
OIL PUMP SECONDARY
188
GASKET KIT , NO LONGER AVAILABLE
189
SPACER TUBE FOLLOWER TO DRIVE SHAFT
190
SCREW , Replaced By: N304017006027
190
SCREW APPARATUS PLATE M 6X45
191
SPRING WASHER LICENSE PLATE TO BRACKET
192
GASKET , Replaced By: A1122771880
192
GASKET
193
SENDER UNIT
194
SEAL RING , NOT INCLUDED IN RANGE OF DELIVERY 112 270 11 16
195
SCREW
196
SPRING WASHER AT GENERATOR TERMINAL D+, 010,10/50 UP TO CHASSIS 066175,010,12/52 UP TO CHASSIS 067208 EXCEPT FOR 067205,010,20/60 UP TO CHASSIS 065672,010,22/62 UP TOCHASSIS 068683 012,10/50 UP TO CHASSIS 151591 EXCEPT FOR,SEE FOOTNOTE 074,012,12/52 UP TO CHASSIS 153776 EXCEPT FOR 153758,153760,153771 012,20/60 UP TO CHASSIS 148879 EXCEPT FOR 148827,148837,148844,148850,148852,012,22/62 UP TO CHASSIS 158113
197
GASKET
197
GASKET , Replaced By: A1122771480
198
SCREW OIL LINE TO CRANKCASE
199
SCREW , Replaced By: N304014006004
199
SCREW BRACKET TO CROSS MEMBER
200
SPRING WASHER LICENSE PLATE TO BRACKET
201
TRANSMISSION CASE REAR
202
SEAL RING SCREW PLUG
203
SCREW PLUG MEASURING CONNECTION
204
PAWL , NO LONGER AVAILABLE
205
SPRING
206
SCREW
207
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
208
SPRING
209
PIN
210
GROOVED BALL BEARING INTERMEDIATE BEARING
211
SEAL RING
212
GEAR MAIN SHAFT, NO LONGER AVAILABLE
213
PIN
214
GASKET
214
GASKET , Replaced By: A1122711480
215
SCREW , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
216
SCREW
217
SPRING WASHER BRACKET TO PEDAL ASSEMBLY BEARING BRACKET, 000,001,004,010 UP TO CHASSIS 064105 EXCEPT FOR, SEE FOOTNOTE 2, 10/50, 20/60, 100,101,104,110 UP TO CHASSIS 099641 EXCEPT FOR , SEE FOOTNOTE 3, ALSO INSTALLED ON 099892
218
FLANGE
219
GROOVED NUT
220
LOCK
221
SPEEDOMETER DRIVE
222
DRIVE SHAFT
223
SPEEDOMETER DRIVE
224
BEARING BODY
225
SEAL RING
226
COVER
227
GASKET
228
SCREW PUMP TO BRACKET
228
SCREW COVER PLATE TO BRACKET
229
SPRING WASHER LICENSE PLATE TO BRACKET
999
BALL SOCKET , 016 UP TO CHASSIS 027622 EXCEPT FOR, SEE FOOTNOTE 3, 018 UP TO CHASSIS
999
SWITCH BACK-UP LIGHT, UP TO TRANSMISSION 365563 EXCEPT FOR, SEE FOOTNOTE 6
999
NUT RETAINER HEATER CASE TO FIRE WALL
999
SCREW BRACKET TO SIDE MEMBER,K 168169
999
OUTER DISC , Replaced By: A1092721826
999
SPACER WASHER AS REQUIRED 0.2 MM, 015 FROM TRANSMISSION 005208
999
SHIFTING ROD
999
BOOT , 000,001,004,010,016 FROM CHASSIS 190318 ALSO INSTALLED ON,SEE FOOTN.36,002,003,005,011,017 FROM CHASSIS 034217 ALSO INSTALLED ON SEE FOOTN.37 AND FOOTN.49
999
GEAR INDICATOR , 012 UP TO CHASSIS 058443 EXCEPT FOR, SEE FOOTNOTE 120, 014 UP TO CHASSIS 045293 EXCEPT FOR, SEE FOOTNOTE 121, 015 UP TO CHASSI S 002590
999
OIL FILLER PIPE , 021,023 UP TO CHASSIS 086613, Replaced By: A1082700284, +001A1122700183
999
GEAR INDICATOR , 012 UP TO CHASSIS 058443 EXCEPT FOR, SEE FOOTNOTE 120, 014 UP TO CHASSIS 045293 EXCEPT FOR, SEE FOOTNOTE 121, 015 UP TO CHASSI S 002590
999
OIL FILLER PIPE , 012 FROM CHASSIS 019536, 014 FROM CHASSIS 016088
999
SHIFTING TUBE , 012 UP TO CHASSIS 058443 EXCEPT FOR, SEE FOOTNOTE 120, 014 UP TO CHASSIS 045293 EXCEPT FOR, SEE FOOTNOTE 121, 015 UP TO CHASSI S 002590
999
BEARING BRACKET
999
SHIFTING TUBE , 012 UP TO CHASSIS 058443 EXCEPT FOR, SEE FOOTNOTE 80, 014 UP TO CHASSIS 045293 EXCEPT FOR, SEE FOOTNOTE 81
999
OUTER DISC 2.0 MM
999
OUTER DISC , 017664 EXCEPT FOR 015709-017194
999
SCREW , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1159900238
999
BREATHER TRANSFER CASE
999
LEVER , 012 UP TO CHASSIS 058443 EXCEPT FOR, SEE FOOTNOTE 120, 014 UP TO CHASSIS 045293 EXCEPT FOR, SEE FOOTNOTE 121, 015 UP TO CHASSI S 002590
999
BOOT , 000,001,004,010,016 UP TO CHASSIS 190317 EXCEPT FOR,SEE FOOTN.36,002,003,005,011,017 UP TO CHASSIS 034216 EXCEPT FOR SEEFOOTN.37 AND FOOTN.38
999
GUIDE PIVOT , 000,001,004,010,016 UP TO CHASSIS 190317 EXCEPT FOR,SEE FOOTN.36,002,003,005,011,017 UP TO CHASSIS 034216 EXCEPT FOR SEEFOOTN.37 AND FOOTN.38
999
BUSHING , 012 UP TO CHASSIS 058443 EXCEPT FOR, SEE FOOTNOTE 80, 014 UP TO CHASSIS 045293 EXCEPT FOR, SEE FOOTNOTE 81
999
BRACKET
999
BRACKET
999
LEVER , UP TO CHASSIS 088724
999
BEARING BRACKET , 012 UP TO CHASSIS 058443 EXCEPT FOR, SEE FOOTNOTE 80, 014 UP TO CHASSIS 045293 EXCEPT FOR, SEE FOOTNOTE 81
999
PIN , 012 UP TO CHASSIS 058443 EXCEPT FOR, SEE FOOTNOTE 120, 014 UP TO CHASSIS 045293 EXCEPT FOR, SEE FOOTNOTE 121, 015 UP TO CHASSI S 002590
999
SHIFTING SEGMENT , UP TO CHASSIS 088724
999
COVER
999
GASKET KIT , Replaced By: A1122701800
999
OIL DIPSTICK , 021,023 UP TO CHASSIS 086613
999
BREATHER REPAIR SIZE, 012, 014 UP TO TRANSMISSION 006059, 015 UP TO TRANSMISSION 008636
999
GASKET KIT
999
SPACER WASHER0.1 MM, NO LONGER AVAILABLE
999
SPACER WASHER , Replaced By: A1122710052
999
SPACER WASHER 0.5 MM
999
BUSHING
999
SPACER WASHER AS REQUIRED 0.5 MM
999
SPACER WASHER AS REQUIRED 0.7 MM
999
SPACER WASHER , Replaced By: A1122720052
999
SPACER WASHER 0.20 MM
999
SPACER WASHER 0.15 MM
999
SPACER WASHER , Replaced By: A1122720652
999
SPACER WASHER AS REQUIRED 0.1 MM
999
GUARD PLATE , 015 FROM TRANSMISSION 005208
999
INSULATING RING , NO LONGER AVAILABLE
999
INSULATING RING
999
PIN AS REQUIRED 36 MM
999
PIN 37 MM AS REQUIRED
999
PIN AS REQUIRED 81 MM, 015 FROM TRANSMISSION 002756
999
PIN AS REQUIRED 82 MM
999
BUSHING , 021,023 UP TO TRANSMISSION 002079
999
BUSHING
999
PISTON , 043 UP TO TRANSMISSION 002079 NO LONGER AVAILABLE
999
SCREW , 009013
999
PIN REPAIR SIZE 5.5 MM, NOT INCLUDED IN RANGE OF DELIVERY 112 270 11 16
999
SPRING
999
SPRING , NO LONGER AVAILABLE
999
SPRING
999
SPRING OUTSIDE, NO LONGER AVAILABLE
999
SPRING , NO LONGER AVAILABLE
999
SCREW PLUG , 014 UP TO TRANSMISSION 000903
999
GROMMET OIL LINE TO CONVERTER HOUSING
999
PLUG , 014 FROM TRANSMISSION 000904, 015 FROM TRANSMISSION 006447
999
FILTER RANGE OF DELIVERY COMPRISES:, 021,023 FROM TRANSMISSION 006751-009935, FROM TRANSMISSION 023011
999
AUTOMATIC TRANSMISSION , ON SPECIAL REQUEST
999
VALVE BODY ASSEMBLY , NO LONGER AVAILABLE 012 FROM CHASSIS 003650
999
VALVE BODY ASSEMBLY , 012 FROM CHASSIS 003650 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
PISTON , NO LONGER AVAILABLE
999
LINE VACUUM
999
SEAL RING
999
SPACER RING SUPPORT TO OIL PAN
999
SCREW CLAMP MOUNTING
999
WASHER , UP TO CHASSIS: 017 029988 114 000523 117 064694
999
WASHER
999
LOCK WASHER
999
LOCK WASHER 3/2-WAY SOLENOID VALVE TO BRACKET
999
LOCK WASHER
999
LOCK WASHER TAIL LAMP TO BRACKET
999
SPRING WASHER , Replaced By: N000137004202
999
SPRING WASHER GROUND CABLE TO TRANSMISSION
999
SPRING WASHER STEERING COLUMN BRACKET TO CAB
999
SCREW HYDRAULIC CLUTCH TO ENGINE, 021,023 UP TO CHASSIS 086009
999
SCREW , Replaced By: N304017010050
999
SCREW FLOOR TO FRAME M 6X16
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N304017006018
999
SCREW , Replaced By: N304017006034
999
SCREW COVER PLATE TO BRACKET
999
SCREW
999
SCREW , Replaced By: N304017008016
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017008034
999
SCREW , Replaced By: A0089907401
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
NUT TACHOGRAPH TO BRACKET
999
NUT CYLINDER TO BRACKET TO0002902112
999
NUT
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
WOODRUFF KEY PRIMARY PUMP TO CONVERTER HOUSING
999
SEAL RINGTO 001 431 72 14
999
BALL SOCKET
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
SCREW COVER PLATE TO COVER PLATE M 6 X 10
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
SCREW PIPE CLAMP
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
SCREW , Replaced By: N304017010055
999
NUT BATTERY MOUNTING
999
NUT BATTERY CABLE
999
THREADED INSERT
999
THREADED INSERT REPAIR SIZE
999
THREADED INSERT REPAIR SIZE
999
THREADED INSERT REPAIR SIZE
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
