Поз.
Артикул
Описание
10
HEAT SHIELD TO EXHAUST MANIFOLD
10
HEAT SHIELD TO EXHAUST MANIFOLD
20
EXTERNAL HEXAL. HD. BOLT HEAT GUARD
30
HEAT SHIELD TO THREE-WAY CATALYTIC CONVERTER
30
HEAT SHIELD TO THREE-WAY CATALYTIC CONVERTER
40
HEXALOBULAR BOLT BRACKET MOUNTING M8X16,V 207570
60
SHIELDING TO FIRE WALL,RECHTS
70
HEXAGON NUT W COLLAR BRACKET MOUNTING
80
SHIELDING TUNNEL,FRONT, J 20130715 V 00123320130918
80
SHIELDING TUNNEL,FRONT
80
SHIELDING TUNNEL,FRONT, J 20130715 V 00000120130404
80
SHIELDING TUNNEL,FRONT
80
SHIELDING TUNNEL,FRONT, J 20130715 V 00123220130918
80
SHIELDING TUNNEL,FRONT, J 20130715 V 00000020130404
90
HEXAGON NUT W COLLAR BRACKET MOUNTING
100
SHIELDING OVER CATALYST
100
SHIELDING OVER CATALYST, J 20120702
100
SHIELDING OVER CATALYST, J 20120702 V 00000120130404
120
HEAT SHIELD TUNNEL, TOP
120
HEAT SHIELD TUNNEL, TOP
130
SCREW W RND. HEXAL. HEAD ENGINE COMPARTMENT FRONT COVERING
150
SHIELDING TO FRAME-TYPE INTEGRAL SUPPORT
160
SCREW
170
CLIP-TYPE NUT LINING TO RIGHT LONGITUDINAL MEMBER 4,8
180
COVER REAR SUBFRAME
180
COVER REAR SUBFRAME
190
EXPANSION RIVET FASTENING FOR LINING
200
SHIELDING ABOVE POSTERIOR MUFFLER
210
HEXAGON NUT W COLLAR BRACKET MOUNTING
250
SCREENING PLATE ABOVE FUEL TANK
270
SCREENING PLATE EXHAUST GAS RECIRCULATION VALVE
280
SCREW CONDENSER TO CHARGE AIR INTERCOOLER M6 X 12
