Поз.
Артикул
Описание
5
SEAT FRAMEWORK RIGHT, LESS ELECTRIC MOTORS,LESS SAFETY BELT, LESS BELT LOCK
5
SEAT FRAMEWORK LEFT, LESS ELECTRIC MOTORS,LESS SAFETY BELT, LESS BELT LOCK
5
SEAT FRAMEWORK , Replaced By: A1299103620
5
SEAT FRAMEWORK , Replaced By: A1299103520
8
TAKE-UP DEVICE
11
PULL UNLOCKING MECHANISM INSIDE,F 009043
11
PULL ,F 009042 ORDER ALSO: 1X 129 910 03 71,LEFT, OR1X 129 910 04 71,RIGHT, Replaced By: A1299100474, +001A1299100374
14
DETENT , Replaced By: A1299101661, +001A1298202607
14
DETENT , Replaced By: A1299101561, +001A1298202507
14
DETENT INSIDE RIGHT
14
DETENT INSIDE LEFT
17
SCREW SEAT FORE AND AFT ADJUSTMENT TO GUIDE RAIL
20
WASHER ,000252
20
WASHER , Replaced By: A1839903540
23
SCREW , Replaced By: A1299900921
23
SCREW AT CUSHION FRAME
26
WASHER AT CUSHION FRAME
32
BUSHING
35
BUSHING
38
BUSHING
41
LEVER LEFT
41
LEVER RIGHT
41
LEVER , Replaced By: A1299100471, +001A1299100374, +001A1299100474
41
LEVER , Replaced By: A1299100371, +001A1299100374, +001A1299100474
44
PULL BACKREST LIMITATION
47
SCREW
50
DETENT OUTSIDE LEFT
50
DETENT OUTSIDE RIGHT
50
DETENT , Replaced By: A1299101461
50
DETENT , Replaced By: A1299101361
53
PULL ,F 009042 ORDER ALSO: 1X 129 910 03 71,LEFT, OR1X 129 910 04 71,RIGHT, Replaced By: A1299100374, +001A1299100474
53
PULL UNLOCKING MECHANISM OUTSIDE,F 009043
56
SCREW , Replaced By: A1299900921
56
SCREW AT CUSHION FRAME
59
WASHER AT CUSHION FRAME
62
BUSHING
62
BUSHING , Replaced By: A1299925901
65
BUSHING , Replaced By: A1299925801
65
BUSHING
68
BUSHING
71
BUSHING
74
BUSHING
77
BUSHING
80
SCREW AT CUSHION FRAME
80
SCREW , Replaced By: A1299900921
83
WASHER AT CUSHION FRAME
86
SCREW CROSS MEMBER TO FRAME AND RAIL,OUTSIDE
89
WASHER , 000420
89
WASHER , Replaced By: A1839904240
92
BUSHING
95
SCREW CROSS MEMBER TO FRAME AND RAIL,INSIDE
98
WASHER , 000420
98
WASHER , Replaced By: A1839904240
101
BUSHING
104
SUPPORT LEFT
104
SUPPORT , Replaced By: A1299101095, +001A1299100689, +001A1299100889
104
SUPPORT , Replaced By: A1299100995, +001A1299100589, +001A1299100789
104
SUPPORT
107
BUSHING
110
BUSHING
113
BUSHING
113
BUSHING , Replaced By: A1299925901
