Поз.
Артикул
Описание
5
STEER. COLUMN JACKET TUBE OUTSIDE
10
BRACKET BRACKET TO STEERING COLUMN JACKET TUBE
15
BUSHING BRACKET TO STEERING COLUMN JACKET TUBE
20
PIN BRACKET TO STEERING COLUMN JACKET TUBE
25
NUT
30
COMBINATION BOLT
30
SCREW STEERING COLUMN JACKET TUBE TO CROSS MEMBER
35
STEER.COLUMN JACKET TUBE INSIDE,F 079796
40
BALL BEARING
45
DISC SPRING , ONLY APPLICABLE TO ELECTRICALLY ADJUSTABLE STEERING COLUMN
50
SNAP RING , F264121
55
RING , C 014018 J 016700
60
LOCK RING , ONLY APPLICABLE TO ELECTRICALLY ADJUSTABLE STEERING COLUMN
65
LOCK
70
NUT
75
CONICAL SLEEVE , ONLY APPLICABLE TO ELECTRICALLY ADJUSTABLE STEERING COLUMN
80
SNAP RING
85
SCREW COLLAR , ONLY APPLICABLE TO ELECTRICALLY ADJUSTABLE STEERING COLUMN
90
LOCK RING. RETAINING RING ROLLER TO BRACKET TO 957 891 03 20, 04 20
95
STEERING SHAFT TOP,F 079796
100
LOCK
105
STEERING SHAFT BOTTOM
110
NUT
115
SPRING
120
SEAL RING
125
BOOT
130
BRACKET , ONLY APPLICABLE TO ELECTRICALLY ADJUSTABLE STEERING COLUMN C 014018 J 016700
135
SCREW BRACKET TO STEERING COLUMN JACKET TUBE
140
DISC SPRING BRACKET TO STEERING COLUMN JACKET TUBE
145
SCREW
150
CLAMPING PIECE
155
LOCK RING21 MM
160
ELECTRIC MOTOR HEIGHT ADJUSTMENT
165
SCREW
170
SENDER UNIT
175
COVER
175
COVER
180
SPRING
185
ELECTRIC MOTOR FORE AND AFT ADJUSTMENT
185
ELECTRIC MOTOR FORE AND AFT ADJUSTMENT
190
PIN
195
LOCK HOSE FASTENING
200
WASHER EXHAUST MUFFLER TO STRAP
205
SCREW GRIP RAIL MOUNTING M 8 X 25
210
ROD
210
ROD
215
COMBINATION BOLT
220
COVERING ,A 122641
225
PANELLING ONLY USED W/TEMPOMAT (CRUISE CONTROL),F 148130NO.9051I NO.5076I... I NO.8316I NO.8F95I... I NO.3112I NO.7102I
