Поз.
Артикул
Описание
5
BEARING BRACKET ,B 236460
8
SUPPORT
8
BRACKET , Replaced By: A2022670161
10
REPAIR KIT SHIFT LEVER, C 051570 ALSO INSTALLED IN C 049998,C 050114,C 050142,C 050155,C 050159,C 050192,C 050264,C 050311,C 050426,C 050475,C 050501,C 050513,C 050535,C 050566, C 050608,C 050637,C 050648,C 050750,C 050761,C 050794,C 050898,C 050935,C 050977,C 051038,C 051046,C 051111,C 051147,C 051188, C 051197,C 051206,C 051269,C 051274,C 051275,C 051278,C 051286,C 051390,C 051446,C 051450,C 051463,C 051470,C 051494, EXCEPT C 051620,C 051693,C 051717,C 052062,C 052695,C 052921,C 053196,C 053290,C 053429,C 058937,C 059965
10
REPAIR KIT SHIFT LEVER
14
SPRING SHIFT LEVER
17
BUSHING
20
SHIFT LEVER
21
SHIFT LEVER , A 242084
23
LOCK PLATE PUSH ROD TO CLUTCH PEDAL
26
NUT
29
PIN
32
BUSHING
35
LOCK PLATE
37
SHIFTING TUBE FOUR-GATE SHIFT, 124.0,124.1 : F 063053 124.2,124.3 : F 079077
41
PIN
44
WASHER SHIFTING TUBE
47
SPRING , Replaced By: A1249932101
47
SPRING SHIFTING TUBE
50
SNAP RING SHIFTING TUBE
53
STOP
53
STOP , F 272214
56
SCREW
59
PIN
62
LOCK
65
WASHER , 124.0,124.1 : F 063053 124.2,124.3 : F 079077
68
BUSHING , 124.0,124.1 : F 063053 124.2,124.3 : F 079077
71
SPACER WASHER , 124.0,124.1 : F 063053 124.2,124.3 : F 079077
74
DISC SPRING
76
SPRING , 124.0,124.1 : F 063053 124.2,124.3 : F 079077
76
SPRING , Replaced By: A2019936101
78
WASHER , 124.0,124.1 : F 063053 124.2,124.3 : F 079077
79
LEVER 1ST AND 2ND SPEED, 124.0,124.1 : F 063053 124.2,124.3 : F 079077
82
LEVER 3RD AND 4TH SPEED, 124.0,124.1 : F 063053 124.2,124.3 : F 079077
85
LEVER 5TH SPEED AND REVERSE
88
SLOTTED GATE
88
SLOTTED GATE , Replaced By: A2022670347
88
SLOTTED GATE , Replaced By: A2022670947
92
SCREW
95
BEARING
95
BEARING , Replaced By: A2022670005
98
SCREW
101
HANDLE , A 192208 EXCEPT FOR A 159651 - A 192207 WITH CODE 856 AUSTRALIA UP TO END OF MODELYEAR 94NO.9045I NO.5070I NO.8310I NO.8317I NO.8317I NO.6121I NO.3111I NO.7102I
101
HANDLE GEARSHIFT LEVER WITH LEATHER COVER ELEGANCE, A 242084NO.9045I NO.5070I NO.8310I NO.8310I NO.8F94I ------ I NO.3111I NO.7102I, Replaced By: A2102671810
101
HANDLE LEATHER COVER, A 242084 ORDER ADDITIONALLY: BADGE FOR SHIFT LEVER HANDLE ES2 : NO.9045 BLACK
102
BADGE BADGE FOR SHIFT LEVER HANDLE, A 242084 NOT CARRIED AS A SPARE PART
104
BRACKET
107
GASKET BEARING BRACKET TO TUNNEL
110
SCREW
113
SHIFTING ROD 1ST AND 2ND SPEED
116
SHIFTING ROD
119
SHIFTING ROD 5TH SPEED AND REVERSE
122
END PIECE
125
BUSHING
125
BUSHING FROM LEVER TO VALVE BODY ASSEMBLY
128
NUT
131
PIN LOCK SHIFTING ROD
