Поз.
Артикул
Описание
10
SCREENING FRAME-TYPE INTEGRAL SUPPORT,LEFT
20
TAPPING SCREW RADIATOR GRILLE SHELL TO ENGINE HOOD 4.8X13
30
SCREW
40
LOCK RIGHT PANELLING TO SIDE MEMBER
50
SCREENING FRAME-TYPE INTEGRAL SUPPORT,RIGHT
60
TAPPING SCREW RADIATOR GRILLE SHELL TO ENGINE HOOD 4.8X13
70
SCREW
80
LOCK RIGHT PANELLING TO SIDE MEMBER
120
SCREENING FIRE WALL,RIGHT, E 01938420040430 A 67972220040604 F 58363320040606
120
SCREENING FIRE WALL,RIGHT, F 58363320040606
120
SCREENING FIRE WALL,RIGHT
120
SCREENING FIRE WALL,RIGHT
120
SHIELDING FIRE WALL,RIGHT, E 01938520040430 A 67972320040604 F 58363420040606 R 16772320040917, Replaced By: A2036800622
120
SHIELDING FIRE WALL,RIGHT, F 58363420040606, Replaced By: A2036826471
130
HEXAGON NUT W COLLAR BRACKET MOUNTING
140
SHEET METAL SCREW ALARM UNIT TO STRUT
140
TAPPING SCREW STEERING-JOINT BOOT COVER 4.8X9.5
160
SCREENING BOOT TO STEERING
170
SHEET METAL SCREW ALARM UNIT TO STRUT
180
LOCK RIGHT PANELLING TO SIDE MEMBER
190
SCREW
200
SCREENING FLOOR,LEFT
210
HEXAGON NUT W COLLAR BRACKET MOUNTING
220
SCREENING MAIN FLOOR,ON THE RIGHT
230
HEXAGON NUT W COLLAR BRACKET MOUNTING
250
SCREENING AT TUNNEL ABOVE CATALYST
260
HEXAGON NUT W COLLAR BRACKET MOUNTING
270
SCREENING ABOVE CENTRAL MUFFLER
280
HEXAGON NUT W COLLAR BRACKET MOUNTING
300
SCREENING ABOVE POSTERIOR MUFFLER
310
HEXAGON NUT W COLLAR BRACKET MOUNTING
320
SCREW PANELLING TO SIDE MEMBER,BOTTOM
