Поз.
Артикул
Описание
11
PROPELLER SHAFT FROM TRANSMISSION TO INTERMEDIATE BEARING 1439 MM
16
GREASE NIPPLE , Replaced By: N071412008102
21
PROTECTIVE CAP
26
DRIVE FLANGE
31
UNIVERSAL JOINT CROSS WITH BUSHINGS, IF REQUIRED,ORDER LOCK RINGS ADDITIONALLY
36
NEEDLE SET164 PIECES, BEARING BUSHING O..D.,38 MM
41
GREASE NIPPLE
46
SNAP RING2.500 MM
46
SNAP RING2.650 MM
46
SNAP RING2.700 MM
46
SNAP RING2.600 MM
46
SNAP RING2.750 MM
46
SNAP RING2.550 MM
51
CENTERING FLANGE PROPELLER SHAFT BEARING
56
PROTECTIVE CAP
61
NUT FOLLOWER FLANGE TO PROPELLER SHAFT
66
REPAIR KIT INTERMEDIATE SHAFT BEARING TO 318 410 03 01
71
RUBBER MOUNTING PROPELLER SHAFT BEARING
76
BALL BEARING PROPELLER SHAFT BEARING
81
BEARING RING , INTERMEDIATE BEARING, BALL BEARING WITH LOCK
86
REINFORCEMENT BRACKET TO CROSS MEMBER,024208
91
SCREW CROSS MEMBER TO FRAME M 10X30
96
NUT BRACKET TO CROSS MEMBER
101
WASHER STRUT TO CROSS MEMBER
111
PROPELLER SHAFT FROM INTERMEDIATE BEARING TO REAR AXLE 1672 MM
116
UNIVERSAL JOINT YOKE
121
GREASE NIPPLE , Replaced By: N071412008102
126
DRIVE FLANGE
131
UNIVERSAL JOINT CROSS WITH BUSHINGS, IF REQUIRED,ORDER LOCK RINGS ADDITIONALLY
136
NEEDLE SET164 PIECES, BEARING BUSHING O..D.,38 MM
141
GREASE NIPPLE
146
SNAP RING2.600 MM
146
SNAP RING2.750 MM
146
SNAP RING2.500 MM
146
SNAP RING2.550 MM
146
SNAP RING2.700 MM
146
SNAP RING2.650 MM
151
SEAL RING , PROPELLER SHAFT WITH BOOT
156
SEAL HOLDER , PROPELLER SHAFT WITH BOOT
161
DRIVE FLANGE
166
UNIVERSAL JOINT CROSS WITH BUSHINGS, IF REQUIRED,ORDER LOCK RINGS ADDITIONALLY
171
NEEDLE SET164 PIECES, BEARING BUSHING O..D.,38 MM
176
GREASE NIPPLE
181
SNAP RING2.650 MM
181
SNAP RING2.500 MM
181
SNAP RING2.700 MM
181
SNAP RING2.750 MM
181
SNAP RING2.600 MM
181
SNAP RING2.550 MM
186
BOOT
191
WIRE RING , WITH BOOT
196
CLAMP , WITH BOOT
201
SCREW , Replaced By: A3539900001
201
HEX. HEAD SCREW. SCREW PROPELLER SHAFT TO PROPELLER SHAFT BEARING AND TO REAR AXLE, LOCK WASHER MUST NOT BE INSTALLED
206
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
211
NUT FROM PROPELLER SHAFT TO FRONT AXLE
