Поз.
Артикул
Описание
10
DASHPOT REFRIGERANT, A 00191920061002
15
PRESSURE SENSOR
20
NUT CLAMP TO BRACKET
30
REFRIGERANT LINE FROM CONDENSER TO LIQUID TANK, A 00191920061002
40
O-RING. SEAL RING9.5 X 2.5
45
GUIDE PRESSURE LINE TO CONDENSER
60
HEXALOBULAR BOLT DELIVERY LINE TO PUMP M6X25
70
NUT , Replaced By: N913023006001
80
LINE HOLDER AC WIRING
90
CLAMP CABLE HARNESS MOUNTING
100
HEXALOBULAR BOLT DELIVERY LINE TO PUMP M6X25
110
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
120
NUT CLAMP TO BRACKET
130
REFRIGERANT LINE FROM LIQUID TANK TO EXPANSION VALVE
130
REFRIGERANT LINE FROM LIQUID TANK TO EXPANSION VALVE
135
GUIDE PRESSURE LINE TO CONDENSER
140
O-RING. SEAL RING9.5 X 2.5
145
SEAL RING HOSE TO EXPANSION VALVE 7.5 MM
150
HEXALOBULAR BOLT DELIVERY LINE TO PUMP M6X25
280
REFRIGERANT LINE FROM EXPANSION VALVE SEPARATION POINT, A 01811620080307
280
REFRIGERANT LINE FROM EXPANSION VALVE SEPARATION POINT, A 01811620080307
285
SEAL RING HOSE TO CONDENSER 14 MM
290
VALVE SUCTION LINE
300
CAP
310
NUT , Replaced By: N913023006001
320
HEXALOBULAR BOLT. SCREW CYLINDER HEAD COVER TO CYLINDER HEAD M 6X30
350
SEAL BOTTOM LEFT
360
SEAL BOTTOM RIGHT, A 01539920071205
360
SEAL BOTTOM RIGHT, A 01539920071205, Replaced By: A2218320398
370
SEAL TOP LEFT
380
SEAL TOP RIGHT, A 01539920071205
390
CLIP AT PARTITION PANEL
400
NUT BRACKET TO BODY SHELL M6
410
GROMMET MOUNTING, REFRIGERANT LINE
420
FASTENER BUTTON AT SOLENOID VALVE,A 258245
430
REFRIGERANT LINE SUCTION LINE TO COMPRESSOR
435
SPACER RING TO INDUCTION LINE
460
SEAL RING SUCTION LINE 13.7X2.5 MM, Replaced By: A0139974745
480
REFRIGERANT LINE PRESSURE LINE TO COMPRESSOR
485
GUIDE PRESSURE LINE TO CONDENSER
500
SEAL RING FROM LIQUID TANK TO T-FITTING
505
O-RING. SEAL RING9.5 X 2.5
510
NUT , Replaced By: N913023006001
540
GUIDE SIGN REFRIGERANT
540
GUIDE SIGN REFRIGERANT
540
GUIDE SIGN REFRIGERANT
900
CLUTCH. PIN BUSHING HOUSING SIREN
