Поз.
Артикул
Описание
20
SEAL RING LOW PRESSURE LINE TO STEERING
30
SUPPORT RING HIGH PRESSURE LINE TO STEERING 11MM, A 83219220050630 E 01999920070101
40
HOLLOW SCREW DELIVERY LINE TO PUMP
45
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
50
HEXALOBULAR BOLT. SCREW BRACKET TO TRANSMISSION M 6X15
60
HEXALOBULAR BOLT. SCREW BRACKET TO TRANSMISSION M 6X15
70
HOSE FROM STEERING TO COOLING PIPE
70
LINE
80
RUBBER RING
90
SEAL RING LOW PRESSURE LINE TO STEERING
100
HOSE CLAMP FUEL LINE TO SENDER UNIT
110
HEXALOBULAR BOLT BRACKET MOUNTING M8X16,V 207570
120
HEXALOBULAR BOLT. SCREW BRACKET TO TRANSMISSION M 6X15
120
SCREW
140
HOSE CLAMP FUEL LINE TO SENDER UNIT
140
HOSE CLAMP LOW PRESSURE HOSE TO COOLER PIPE OR PUMP 15.5 MM, A 54101820030515 E 02000020070101
