Поз.
Артикул
Описание
10
SEALING PARTITION ENGINE COMPARTMENT
20
SEALING FRONT END LEFT
30
SEALING FRONT END RIGHT
50
STRUT OSCILLATING SUPPORT
60
FUSE PENDELUM SUPPORT TO BRAKE UNIT
70
GROMMET BRAKE CABLE TO REAR AXLE
110
STRUT LEFT
110
STRUT LEFT
120
STRUT RIGHT
120
STRUT RIGHT
130
STRUT RIGHT REAR
130
STRUT RIGHT REAR
130
STRUT RIGHT REAR
130
STRUT RIGHT REAR
150
HEXALOBULAR BOLT STRUT TO BODY-IN-WHITE, LEFT M8X40
160
THR.ROLL.FILL.HD SCREW STRUT TO BODY-IN-WHITE, LEFT M8X54, A 20130930
170
HEXALOBULAR BOLT STRUT TO BODY-IN-WHITE, LEFT M8X40
180
THR.ROLL.FILL.HD SCREW STRUT TO BODY-IN-WHITE, LEFT M8X54, A 20130930
190
HEXALOBULAR BOLT CENTRAL CONSOLE TO INSTRUMENT PANEL M6X30, A 20130328
200
THR.ROLL.FILL.HD SCREW STRUT TO BODY-IN-WHITE, LEFT M8X54, A 20130930
210
STRUT CENTRAL
220
HEXALOBULAR BOLT CENTRAL CONSOLE TO INSTRUMENT PANEL M6X30, A 20130328
230
PARTITION LOWER PART, LEFT
240
LOCK NUT CENTER REINFORCEMENT TO HOUSING CENTER CONSOLE 4.8/0.5-2.5 MM
245
WELD STUD ON BOTTOM LEFT PARTITION WALL
250
PARTITION LOWER PART, RIGHT
260
LOCK NUT CENTER REINFORCEMENT TO HOUSING CENTER CONSOLE 4.8/0.5-2.5 MM
270
CABLE BRACKET TO PARTITION WALL, RIGHT
275
FILLISTER HD SCREW MOUNTING SHIELD RIGHT 5X16
280
HEXAGON NUT W COLLAR CENTER MUFFLER SHIELD AT MAIN FLOOR
280
NUT-AND-WASHER ASSEMBLY EVAPORATOR HOUSING TO CROSSMEMBER M6
290
PARTITION TOP CENTER
290
PARTITION TOP CENTER
300
TAPPING SCREW STEERING COLUMN MOUNTED SWITCH PLUGCONNECTION 4.8X13
360
NUT-AND-WASHER ASSEMBLY EVAPORATOR HOUSING TO CROSSMEMBER M6
360
NUT ENGINE MOUNTING M8
360
NUT-AND-WASHER ASSEMBLY RUBBER MOUNTING TO FRAME M8
360
NUT , Replaced By: N913023006001
370
STOP PLUG SIDE MEMBER,REAR M8
380
HEXALOBULAR BOLT MOUNTING PARTS M8X16
380
BOLT AT BRACKET
380
NUT , Replaced By: N913023006001
380
HEXALOBULAR BOLT GROUND CABLE TO GENERATOR M6X20
380
HEXAGON HEAD BOLT CONTROL ARM, LINKAGE ADJUSTER ON BEARING BRACKET M8X12
380
SCREW BRACKET TO SIDE MEMBER M8X20
385
BLIND PLUG AT PARTITION PANEL
385
BLIND PLUG AT PARTITION PANEL
390
BLIND PLUG
390
CONSOLE AT DAMPER TOWER, RIGHT
390
CONSOLE AT LEFT DAMPER DOME
460
REINFORCEMENT AT FIRE WALL
460
SUPPORT
