Поз.
Артикул
Описание
157
CONNECTOR MASTER CYLINDER,CONNECTION "2.1",4 338292
215
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
220
SEAL RING FUEL LINE TO FEED PUMP
221
HOLLOW SCREW , Replaced By: N915036010108
221
HOLLOW SCREW FUEL LINE TO FEED PUMP
221
HOLLOW SCREW OIL LINE TO TRANSMISSION
221
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
222
SEAL RING LINE CONNECTION
222
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
224
FITTING TWO-WAY VALVE "12",4 4121264 691315
232
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
233
SCREW CONSOLE TO SIDE MEMBER
234
WASHER
235
NUT SUPPORT TO SIDE MEMBER
265
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
266
LOOM TIE LINE MOUNTING
267
SCREW COVER PLATE TO BRACKET
268
NUT , Replaced By: N913002006009
268
NUT OIL TANK TO BRACKET
269
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
270
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
271
SCREW , 10/20 695199 50/60 695577 8 000001
272
NUT , Replaced By: N913002006009
272
NUT OIL TANK TO BRACKET
275
LINE1450 MM
277
BRACKET LINE MOUNTING
277
BRACKET LINE MOUNTING
278
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
279
SCREW , Replaced By: N304017008021
279
SCREW PIPE CLAMP
280
NUT , Replaced By: N913004008001
280
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
315
VERTEILERSTUCK. DISTRIBUTOR REAR AXLE,4 478330
315
DISTRIBUTOR REAR AXLE,4 478330
321
LINE FROM BRAKE POWER REGULATOR TO REAR AXLE BRAKE HOSE
328
LINE FROM CONNECTOR TO TEST CONNECTION 2800 MM,4 478330
332
BRAKE HOSE AT REAR AXLE
333
BRAKE HOSE
333
BRAKE HOSE
340
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
346
ANGLE AT FRAME, FRONT
347
GROMMET BATTERY CASE
348
SCREW END PIECE TO EXHAUST PIPE M 10X25
348
SCREW END PIECE TO EXHAUST PIPE M 10X25
348
SCREW , Replaced By: N304017010002
348
SCREW BRACKET TO SIDE MEMBER
348
SCREW END PIECE TO EXHAUST PIPE M 10X25
349
NUT , Replaced By: N910113010000
349
NUT STRAP TO BRACKET
352
BRACKET LINE MOUNTING
354
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
364
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
364
SCREW , Replaced By: A0029903712
364
SCREW , Replaced By: N000000001149
364
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
365
NUT , Replaced By: N913004006001
365
NUT PUMP TO BRACKET
366
SPACER TUBE , Replaced By: A4082910153
366
SPACER TUBE
370
LINE FROM CLUTCH MASTER CYLINDER TO HYDRAULIC HOSE 350 MM,556500-604337
371
CONNECTOR OIL DELIVERY LINE
378
LINE FROM TEST CONNECTION TO RIGHT FRONT WHEEL BRAKE HOSE
466
VERTEILERSTUCK. DISTRIBUTOR REAR AXLE,4 478330
466
DISTRIBUTOR REAR AXLE,4 478330
467
SCREW VALVE TO BRACKET
467
SCREW , Replaced By: N304017008034
467
SCREW BRACKET TO CROSS CONNECTION STRUT
468
SPACER TUBE FRONT AXLE REGULATING SOLENOID VALVE
469
NUT , Replaced By: N913004008001
469
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
469
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
472
BRACKET LEFT,6028918 000001
472
BRACKET RIGHT,7914218 000001
473
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
474
SCREW , Replaced By: N304017008016
474
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
475
CLAMP BRAKE LINE MOUNTING
475
CLAMP BRAKE LINE MOUNTING
476
HOSE BRAKE LINE TO REAR AXLE,4 644238
476
HOSE BRAKE LINE TO REAR AXLE,4 644238
478
LINE FROM TEST CONNECTION TO LEFT FRONT WHEEL BRAKE HOSE 1400 MM
480
LINE FROM TEST CONNECTION TO RIGHT WHEEL CYLINDER 700 MM,4 644237
482
BRACKET
483
SCREW BRACKET TO SIDE MEMBER
483
SCREW PIPE CLAMP
483
SCREW , Replaced By: N304017008021
484
NUT STRAP TO BRACKET
484
NUT , Replaced By: N910113010000
484
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
484
NUT , Replaced By: N913004008001
485
CLAMP ,K 147121, Replaced By: N000000000319
485
CLAMP , Replaced By: N916016008200
485
CLAMP , Replaced By: A3604300143
486
SCREW COVER PLATE TO BRACKET
487
NUT PUMP TO BRACKET
487
NUT , Replaced By: N913004006001
550
PROTECTIVE CAP COMPRESSED AIR LINE MOUNTING
751
BRACKET BRAKE BOOSTER,4 373946
751
BRACKET BRAKE BOOSTER,4 373946
999
BRAKE INTERMEDIATE SHAFT , ONLY APPLICABLE TO BEVERAGE VEHICLES
999
BRAKE CABLE BRAKE POWER REGULATOR, ONLY APPLICABLE TO BEVERAGE VEHICLES
999
VALVE GASKET KIT TO 003 429 16 44,BOSCH,UP TO 03.82
999
VALVEBOSCH
999
PROTECTIVE CAP , Replaced By: A0004217187
999
BRACKET. LOCK , Replaced By: A6525040038
999
BRAKE HOSE , Replaced By: A0004289535
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
SHUT-OFF COCK , Replaced By: A0004291431
999
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
SPRINGTO 000 429 16 31,4 940458
999
SPRINGTO 000 429 16 31,4 940458
999
SEAL RINGTO 000 429 16 31,4 940458
999
HANDLE (PARTS KIT) TO 001 430 07 81/20 81, UP T0 BOSCH CHARACTERISTIC NUMBER 045
999
HANDLETO 001 430 17 81,KNORR
999
REPAIR KITTO 001 430 18 81/78 81
999
REPAIR KITTO 002 431 83 06, KNORR 90309
999
REPAIR KIT BLEEDER VALVE TO 001 431 67 05,BOSCH
999
REPAIR KITBOSCH
999
VALVE
999
SPACER RING ,4 428462
999
VALVE , Replaced By: A3075530107
999
SLIDETO 000 431 50 14,000 431 24 14
999
VALVE , Replaced By: A0004311316
999
DICHTSCHEIBE. SEAL RING
999
SCREWTO 003 430 72 01,SCHAEFER
999
ACTUATING PARTTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
999
COVERTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
999
ACTUATING PARTTO 001 430 07 81/20 81
999
VALVE , Replaced By: A0004311316
999
THREADED UNION BRAKE CYLINDER
999
VALVE DISC , Replaced By: A0003270032
999
BRAKE BOOSTER , Replaced By: A0004319114
999
GASKET34X2X6 MM,GRAU
999
TEST CONNECTION
999
FILLER CAP , Replaced By: A0004313433
999
LEVER , Replaced By: A0034302881
999
WASHER
999
LEVER TOOTHED
999
LEVER
999
VALVE SEATGRAU
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
PROTECTIVE CAP , Replaced By: A0009979486
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
FILLER CAP , Replaced By: A0004313733
999
BRAKE CYLINDER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0014316514
999
FILLER CAP , Replaced By: A0004315433
999
BRAKE CYLINDER. BRAKE BOOSTER , Replaced By: A0004319114
999
PISTONTO 003 430 07 01,4 2827078 000001-8 001702
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
SEAL RING , Replaced By: A0004319460
999
CUP , Replaced By: A0015864342
999
BRAKE CYLINDER , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 847617, Replaced By: A0014318514
999
BRAKE CYLINDER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 847617, Replaced By: A0014318514
999
CUPTO 000 431 50 14
999
PRESSURE REGULATORBOSCH,4 208907 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
REPAIR KITWABCO
999
SLEEVE , Replaced By: A0007630553
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
T-FITTING 3/2-WAY VALVE
999
T-FITTING , Replaced By: A0019901070
999
T-FITTING DIAPHRAGM CYLINDER,CONNECTION: "11",5 272559
999
PINTO 002 430 90 81
999
PINTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
999
PINTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
999
BUSHINGTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
999
HANDLE , Replaced By: A0009970377
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
HANDLETO 002 430 29 81,WABCO
999
HANDLETO 001 430 08 81,BOSCH
999
HANDLETO 000 429 16 31,4 940458
999
PLUG
999
VALVE , Replaced By: A0034291644
999
VALVE , Replaced By: A0014306581
999
VALVE , Replaced By: A0024300381
999
VALVE PARKING BRAKE KNORR
999
PRESSURE REGULATOR , Replaced By: A0024314906
999
PRESSURE REGULATOR , Replaced By: A0024313406
999
PROTECTIVE CAPTO WABCO
999
BRAKE CYLINDER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 847617, Replaced By: A0014318614
999
BRAKE CYLINDER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 847617, Replaced By: A0014318614
999
PROTECTIVE CAPTO BOSCH
999
PRESSURE REGULATOR , Replaced By: A0024314906
999
SEAL RING28X2 MM,GRAU
999
SEAL RING86X2 MM,GRAU
999
CUPTO 001 431 65 14
999
GASKET , Replaced By: A0004311980
999
PRESSURE REGULATOR"WABCO",486597
999
BRAKE VALVE , Replaced By: A0014313705
999
PRESSURE REGULATOR ,5 148812, Replaced By: A0024314306
999
VALVE , Replaced By: A0014318406
999
VALVE , Replaced By: A0024310406
999
PRESSURE REGULATORWABCO
999
PRESSURE REGULATOR , EXHAUST STOCK OF OLD PARTS FROM CHASSIS 4 208908-5 148812, Replaced By: A0024315906
999
PRESSURE REGULATOR , Replaced By: A0024316006
999
BRAKE CYLINDER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 847617, Replaced By: A0014318614
999
VALVE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0024312906
999
REPAIR KITTO 001 429 20 44,BOSCH
999
REPAIR KIT WHEEL CYLINDER SCHAEFER, FROM REAR AXLE K 029 515,EXCEPT FOR K 029 516,K 029 517 LESS THRUST PIN,USE 000 423 10 88 THRUST PIN
999
REPAIR KIT , Replaced By: A0034201724
999
REPAIR KIT , Replaced By: A0004301107
