Поз.
Артикул
Описание
5
REAR EXHAUST PIPE REAR
5
REAR EXHAUST PIPE REAR
8
THROTTLE HOUSING , ON SPECIAL REQUEST,CHANGE-OVER MUFFLER WITH TAIL PIPE BEHIND CAB
11
THROTTLE HOUSING CHANGE-OVER FLAP
14
LEVER
17
FLAP
20
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
23
SCREW EXHAUST BRAKE SEPARATION POINT
26
SPRING CHANGE-OVER FLAP
29
COVER
32
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
35
SCREW
38
EXHAUST PIPE REAR
38
EXHAUST PIPE REAR
41
BRACKET EXHAUST PIPE TO TOP OF CAB
44
BRACKET
44
BRACKET TAIL PIPE
47
BRACKET TAIL PIPE
50
BRACKET PROTECTIVE PLATE
53
RIVET
56
SUPPORT TOP, UP TO CHASSIS 000552
59
BRACKET CHANGE-OVER FLAP
59
BRACKET CHANGE-OVER FLAP
59
BRACKET REAR EXHAUST PIPE, ON SPECIAL REQUEST,CHANGE-OVER MUFFLER WITH TAIL PIPE BEHIND CAB
62
SCREW CLAMP TO BRACKET AND TO PIPE
65
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
68
NUT
71
CLAMP END PIECE TO EXHAUST PIPE 63.5 MM
74
SCREWM 8X40
77
NUT
80
CLAMP EXHAUST PIPE TO TOP OF CAB
83
CLAMP EXHAUST PIPE TO BRACKET
86
SCREW PIPE CLAMP
86
SCREW , Replaced By: N304017008021
86
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
86
SCREW , Replaced By: N304017008016
86
SCREW
86
SCREW
89
WASHER BRACKET TO LEFT SIDE MEMBER
89
WASHER , Replaced By: N009021008213
92
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
95
NUT
98
PROTECTIVE PLATE BOTTOM
101
PROTECTIVE PLATE
104
SCREW SHIFT CASE TO SLOTTED GATE
107
WASHER COMPRESSED AIR LINE TO BRACKET
107
WASHER , Replaced By: N009021006208
110
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
113
NUT BALL PIVOT TO LEVER
116
LOCK ,A 006845
119
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
122
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
122
SCREW , Replaced By: N304017008016
