Поз.
Артикул
Описание
374
CLAMP310 MM
384
CLAMP320 MM
387
CLAMP360 MM
392
PLATE , Replaced By: A3528910011
392
PLATE PLATFORM MOUNTING
396
PLATE FOR U-BOLTS WITH ADISTANCE OF 110 MM BETWEEN THE ENDS
400
NUT STRAP TO SUPPORT,5 149419
405
PAD , Replaced By: A3528910296
405
BASE , Replaced By: A3528910296
405
BASE PLATFORM MOUNTING
410
PAD , Replaced By: A3528910196
410
BASE , Replaced By: A3528910196
410
BASE , Replaced By: A3528910296
410
BASE PLATFORM MOUNTING
414
BASE TOP
417
PAD TOP
421
BASE TOP
424
BASE TOP
427
FASTENER
430
RUBBER BUFFER
435
FIXTURE CHOCK,755918
435
FIXTURE , Replaced By: A3528900110
999
CLAMP PLATFORM MOUNTING
999
CLAMP , Replaced By: A3608910630
999
CLAMP , Replaced By: A3228910630
999
CLAMP360 MM
999
CLAMP475 MM
999
HINGE
999
CLAMP335 MM
999
CLAMP PLATFORM TO FRAME 395 MM
999
CLAMP390 MM
999
CLAMP405 MM
999
CLAMP PLATFORM TO FRAME 420 MM
999
FASTENER , PART NUMBER HAS BEEN CONVERTED TO THE NEW MODE OF WRITING, Replaced By: A3128900289
999
HINGE , PART NUMBER HAS BEEN CONVERTED TO THE NEW MODE OF WRITING, Replaced By: A3128990251
999
SCREW , 036315
999
WASHER HORN TO ENGINE CROSS MEMBER
999
LOCK WASHER
999
WASHER
999
NUT
999
NUT SPRING CLAMP
999
NUT
999
SCREW
999
SCREW
999
SCREW , FROM CHASSIS 011231 EXCEPT FOR 011232-011236,011255-011259,011269-011273,011307-011311,011336-011340,011352-011357,011394-011399, 011423-011427,011459-011464,011480-011485,011532-011537,011558-011565,011579-011585,011624-011630, 011643-011649,011687-011693,011719-011724,011719-011724,011737-011742,011771-011776,011799-011803, 011842-011847,011870-011875,011906-011910,011927-011932,011957-011962,011985-011990,012019-012023, 012048-012053,012090-012094,012112-012117,012157-012162,012191-012195,012224-012229,012241-012246, 012266-012270,012299-012304,012335-012339.
999
SCREWM 8X45
999
SCREW
999
SCREWM 8X55
999
SCREWM 8X60
999
SCREWM 8X65
999
SCREWM 8X70
999
SCREWM 8X80
999
SCREWM 8X90
999
SCREWM 8X110
999
SCREWM 8X120
999
SCREW , 036316
999
SCREW REAR SIDE PANEL M10X50
999
SCREW PLATFORM PANEL FASTENER M 10X45,604332
999
SCREW BINDING RAIL TO PLATFORM FRONT PANEL M 6X35,604332
999
WASHER , Replaced By: N009021008213
999
WASHER BRACKET TO LEFT SIDE MEMBER
999
NUT , Replaced By: N304032005005
999
NUT IN CASE OF SUBSEQUENT INSTALLATION
