Поз.
Артикул
Описание
2
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
8
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
279
UNION NUT BUTT SCREW CONNECTION
280
GLAND LINE CONNECTION
282
THRUST RING BUTT SCREW CONNECTION
283
SEAL RING , Replaced By: N007603012121
283
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
284
UNION NUT LINE CONNECTION
286
GLAND LINE CONNECTION
287
RESERVOIR *** III (20 L.)
289
VALVE
290
BASE
291
STRAP , Replaced By: A3464305140
291
STRAP , Replaced By: A4375500142
291
STRAP AIR RESERVOIR TO FRAME SIDE MEMBER,5 314334 TO BE ADAPTED DURING ASSEMBLY
302
VALVE (CHECK VALVE)
302
NON-RETURN VALVE. VALVE WITH CHECK VALVE WABCO,5 433388
303
REPAIR KITWABCO
305
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
306
SEAL RING LINE CONNECTION
307
CONNECTOR ,966010
308
CONNECTOR
310
T-FITTING AT AIR RESERVOIR
311
VALVE PARKING BRAKE, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
313
REPAIR KITWABCO
314
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
316
SEAL RING LINE CONNECTION
325
FITTING , Replaced By: A0009970171
325
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
326
BRAKE BOOSTER
330
SCREW PLUG , Replaced By: N007604018101
330
SCREW PLUG
331
SEAL RING VALVE TO VALVE,K 025179
334
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3454307481
336
REPAIR KIT
338
BRACKET HAND BRAKE VALVE
344
FITTING HYDRAULIC LINE TO BRACKET,K 130132
346
NUT , Replaced By: N308675014001
346
NUT JOINT TO BRACKET
348
FITTING , Replaced By: A0039978972
348
FITTING , Replaced By: A0029905971
348
FITTING (PARTS KIT),LINE RUPTURE
349
BRACKET
350
CLAMP
352
BRACKET BRACKET TO REAR AXLE II,4 195521
353
BRACKET
354
CLAMP AT SIDE MEMBER
356
SHIM BRACKET TO LEFT SIDE MEMBER
362
BRAKE LINE COUPLING AT REAR CROSS MENBER
363
VALVETO 000 429 29 30
365
SPRINGTO 000 429 29 30
366
THRUST RING
367
BRACKET TRAILER CONTROL VALVE
368
SHUT-OFF COCK
375
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
376
SEAL RING LINE CONNECTION
378
FITTING SHUTTLE VALVE,CONNECTION: "20"
378
FITTING , Replaced By: A0019972372
380
NUT CHECK VALVE TO AIR RESERVOIR
382
THRUST RING CHECK VALVE TO AIR RESERVOIR
382
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
383
O-RING CHECK VALVE TO AIR RESERVOIR
386
BRACKET AT CYLINDER BLOCK, REAR
390
VALVE (OVERFLOW VALVE),REAR CARRIAGE SECONDARY CONSUMING UNITS "WABCO"
392
REPAIR KIT OVERFLOW VALVE TO 003 429 09 44,WABCO
393
SEAL RING LINE CONNECTION
394
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
394
FITTING , Replaced By: A0009970171
396
SWITCH 3/2-WAY VALVE
397
SWITCH IN BEARING BRACKET,FOR RATCHET-TYPE HAND BRAKE CONTROL
398
PIN
399
WASHER , UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
999
CABLE CONNECTOR1.0-2.6 MM2
999
BOOTTO 000 431 16 14
999
BUSHINGWABCO,5 433388
999
PIN
999
VALVE SEAT RINGWABCO,5 433388
999
SEAL RINGTO 000 429 75 30
999
LINE , Replaced By: A0005516256
999
VALVE CONE , Replaced By: A0004290391
999
VALVE CONEBOSCH
999
CONNECTOR , Replaced By: A0004312031, +001N074302022304
999
DIAPHRAGM
999
SPRINGTO 000 429 75 30
999
DIAPHRAGMTO 001 429 48 44
999
SHUT-OFF COCK , Replaced By: A0004291431
999
CONNECTOR , Replaced By: A0004312031, +001A0004291538
999
COVERTO 000 429 48 30
999
COVERWABCO
999
VALVE (OVERFLOW VALVE)
999
BRAKE LINE COUPLING , Replaced By: A0004297530
999
SHUT-OFF COCK
999
SPRINGTO 000 429 16 31,4 940458
999
SPRINGTO 000 429 16 31,4 940458
999
SEAL RINGTO 000 429 16 31,4 940458
999
BRAKE LINE COUPLING
999
BRAKE LINE COUPLING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0004296730
999
VALVE , Replaced By: A0004299244
999
BRAKE LINE COUPLING AT REAR CROSS MENBER
999
VALVE (OVERFLOW VALVE)
999
VALVE
999
BRAKE LINE COUPLING AT REAR CROSS MENBER
999
REPAIR KITKNORR
999
VALVE , ON 343.1 UP TO CHASSIS 601715 ON 343.3 UP TO CHASSIS 601550, Replaced By: A0004305181
999
GASKET34X2X6 MM,GRAU
999
VALVE SEATGRAU
999
VALVE , ON 343.1 UP TO CHASSIS 601715 ON 343.3 UP TO CHASSIS 601550
999
SEAL RINGTO 000 431 16 14
999
SPRING , ON 343.1 UP TO CHASSIS 601715 ON 343.3 UP TO CHASSIS 601550
999
CUP
999
VALVE , Replaced By: A0004320807
999
RESERVOIR , Replaced By: A0034322701
999
COVERTO 000 429 16 30,BOSCH
999
SPRING CAPSULETO 000 429 16 30
999
NUTTO 000 429 16 30
999
VALVE PARTTO 000 429 16 30
999
VALVE TAPPETTO 000 429 16 30
999
VALVE DISCTO 000 429 48 30
999
VALVE DISCTO 000 429 48 30
999
GASKETTO 000 429 16 30
999
PLUG SOCKET , Replaced By: A3805400181
999
BOOT
999
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
999
PIN BUSHING , Replaced By: A0075458226
999
PLUG
999
REPAIR KITTO 000 429 14 31,5 116581
999
REPAIR KIT
999
RIVET , Replaced By: N910005012080
999
RIVET , Replaced By: N910005012020
999
NUT PRESSURE SWITCH SCREW-CONNECTION M 24X1,5 129167
999
RIVET , Replaced By: N910005012020
999
NUT PRESSURE SWITCH SCREW-CONNECTION M 27X1
999
WASHER PRESSURE SWITCH SCREW-CONNECTION TO M 24X1,5 129167
999
ELBOW FITTING ,4 412125
999
SPRINGTO 000 429 16 30
999
SPRINGTO 000 429 16 30
999
CLAMP LINE CONNECTION
999
GROMMET AT SHOCK ABSORBER BRACKET AND AT FENDER BRACKET
999
HANDLETO 000 429 16 31,4 940458
999
VALVE (RELAY VALVE) GRAU
999
VALVE , Replaced By: A0034295244
999
VALVE OVERFLOW VALVE
999
SEAL RING28X2 MM,GRAU
999
SEAL RING86X2 MM,GRAU
999
PLUG HOUSING 6-POLE
999
PLUG HOUSING BIPOLAR,4 231689
999
PIN BUSHING HOUSING 8-POLE
999
PLUG LESS DETENT,BUT WITH CATCH FOR HOUSING 2.5 MM2
999
PIN BUSHING HOUSING BIPOLAR
999
SEAL RINGTO 000 429 16 30
999
SEAL RINGTO 001 431 37 05,4 375193
999
FITTING , Replaced By: A0039979072
999
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
999
PLUG HOUSING 4-POLE
999
REPAIR KITKNORR
999
REPAIR KITWABCO
999
TS DOUBLE FITTING SOLENOID VALVE
999
VALVE OVERFLOW VALVE
999
VALVE RELAY VALVE KNORR
999
FITTING , Replaced By: A0029906071
999
SEAL RING22.3X2.4 MM,GRAU
999
SEAL RINGTO 000 429 28 95,GRAU
999
SEAL RING *** 47 X 2.5,TO 000 431 12 14
999
SEAL RINGTO 000 429 16 30
999
SOCKET. PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 2,5 MM2
999
SEAL RINGTO 000 429 16 31,4 940458
999
CLAMP FUEL LINE TO BRACKET
999
CLAMP
999
CLAMP DELIVERY AND RETURN LINES
999
PAWL
999
BRACKET FLEXIBLE SHAFT TO TRANSMISSION
999
BRACKET , Replaced By: A3344270041
999
CLAMP
999
CLAMP ELECTRIC CABLE TO FRAME SIDE MEMBER
999
CLAMP COMPRESSED AIR LINE TO BRACKET
999
CLAMP , Replaced By: A3129952420
999
GUIDE BUSHING TWO-WAY VALVE TO FRAME
999
TOOTHED SEGMENT
999
HANDLE
999
CLAMP , Replaced By: A1109950401
999
ELECTRIC CABLE
999
PIN
999
SPRING , Replaced By: A3529930610
999
PLUG EXHAUST BRAKE VALVE, CONNECTION: "20"
999
WASHER AS REQUIRED 2.00MM, UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
999
BUSHING , UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
999
WASHER AS REQUIRED 2.3MM, UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
999
BRACKET
999
ADJUSTING LEVER
999
BRACKET
999
BRACKET
999
STRAP
999
SPACER TUBE , Replaced By: A3094310249
999
BASE AIR RESERVOIR
999
SPACER TUBE CAB
999
BEARING BRACKET
999
PARKING BRAKE
999
BRAKE LEVER
999
ROD FROM HAND BRAKE LEVER TO HAND BRAKE BOOSTER
999
ROD
