Поз.
Артикул
Описание
1
EXHAUST PIPE FRONT,FRONT PART
2
FLANGE GASKET , Replaced By: A3024900080
2
FLANGE GASKET , Replaced By: A4424920080
2
FLANGE GASKET FRONT EXHAUST PIPE TO EXHAUST MANIFOLD, ELIMINATED - NO LONGER REQUIRED
3
SCREW CONNECTOR TO EXHAUST MANIFOLD
3
SCREW FRONT EXHAUST PIPE TO EXHAUST MANIFOLD M 12 X 90
4
SPACER TUBE FRONT EXHAUST PIPE TO EXHAUST MANIFOLD
5
NUT CONNECTOR TO EXHAUST MANIFOLD
6
FRONT EXHAUST PIPE , Replaced By: A3664920201
6
FRONT EXHAUST PIPE , Replaced By: A3664920201
6
FRONT EXHAUST PIPE FRONT,REAR PART, UP TO CHASSIS 792154,FROM CHASSIS 792155,SEE STANDARD VERSION
8
CLAMP ATTACHMENT FOR CHARGE AIR PIPE,HOT
10
EXHAUST MUFFLER , Replaced By: A3464900101
10
EXHAUST MUFFLER , Replaced By: A3464900101
10
EXHAUST MUFFLER
14
SUPPORT , UP TO CHASSIS 723231 EXCEPT FOR 500001-599999, Replaced By: A3464905034, +001A3464905041, +001A3475040012, +002N000127010203, +002N000934010014
14
SUPPORT EXHAUST MUFFLER SUSPENSION, UP TO CHASSIS 792154,FROM CHASSIS 792155,SEE STANDARD VERSION
19
RUBBER MOUNTING
21
BRACKET EXHAUST MUFFLER
22
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
23
NUT , Replaced By: N910113010000
23
NUT STRAP TO BRACKET
24
CLAMP , Replaced By: A3874900041
24
CLAMP EXHAUST MUFFLER TO BRACKET
26
BRACKET REAR EXHAUST PIPE
33
REAR EXHAUST PIPE
33
REAR EXHAUST PIPE
37
CLAMP INTERMEDIATE PIECE
999
NUT , Replaced By: N913004008001
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
LOCK WASHER FITTING TO BRACKET
999
NUT. HEXAGON NUT SHOCK ABSORBER MOUNTING
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
999
SCREW CONSOLE TO SIDE MEMBER
999
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
999
SCREW
999
NUT , Replaced By: N308673012002
999
NUT STRAP TO SUPPORT
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
SCREW , Replaced By: N304017010002
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SCREW , Replaced By: N304017008027
999
LOCK WASHER CONSOLE TO FRAME AND TO AUXILIARY FRAME,RESP.
999
WASHER RADIATOR TO RUBBER MOUNTING
999
WASHER , Replaced By: N000125010532
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125008443
999
BRACKET REAR EXHAUST PIPE
999
BRACKET
999
BRACKET REAR EXHAUST PIPE
