Поз.
Артикул
Описание
330
GASKET
332
HOUSING GEAR INTERLOCK
335
SEAL RING HOUSING,TOP
337
SHAFT GEAR INTERLOCK
338
PIN GEAR INTERLOCK
340
DOWEL PIN. PIN SHIFTING ROD
342
SPRING WASHER , Replaced By: N000137008212
343
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
343
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
343
SCREW , Replaced By: N304017008027
345
SHIFT LEVER GEAR INTERLOCK
345
SHIFT LEVER GEAR INTERLOCK
350
ROD
350
ROD
352
NUT BRACKET TO SUPPORT AND TO END PIECE
352
NUT BRACKET TO SUPPORT AND TO END PIECE
354
YOKE
354
YOKE
357
PIN PULL ROD TO SHIFT LEVER
357
PIN PULL ROD TO SHIFT LEVER
368
HOUSING TO 336 260 31 05 41:27 I0.95 X N, FROM TRANSMISSION 029243 FOR GEAR SET 41:27,RATIO0,95 X ENGINE REVOLUTIONS
372
SPACER WASHER AS REQUIRED 1.40 MM
372
SPACER WASHER AS REQUIRED 1.40 MM
372
SPACER WASHER AS REQUIRED 1.40 MM
375
STUD BOLT
376
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
378
NUT BRACKET TO SUPPORT AND TO END PIECE
380
SEAL RING
381
SHIFTING FORK
384
DRIVE SHAFT
384
DRIVE SHAFT
386
PIN
388
SPRING DRIVE SHAFT
389
BALL P.T.O. SHAFT
391
SLIDING COLLAR P.T.O.
393
GEAR NUMBER OF TEETH: 41
395
BUSHING , NO LONGER AVAILABLE
396
THRUST WASHER DRIVE GEAR
397
CYLINDR. ROLLER BEARING DRIVE SHAFT
399
LOCK RING BEARING TO DRIVE SHAFT,183596
399
LOCK RING BEARING TO DRIVE SHAFT,183596
402
SPACER WASHER AS REQUIRED 4.20 MM, PIECES ARE INAPPLICABLE IT A POWER TAKE OFF N352/1B AND N352/2B IS FITTED
405
COVER REAR P.T.O., PIECES ARE INAPPLICABLE IT A POWER TAKE OFF N352/1B AND N352/2B IS FITTED
405
COVER , Replaced By: A0002644611, +001A0002649580
405
COVER , Replaced By: A0002644411, +001A0002647480
409
SCREW BRACKET TO SIDE MEMBER,5 105538
411
DRIVE SHAFT27 ZAEHNE I0,95 X N MOTOR, FROM TRANSMISSION 029243 FOR GEAR SET 41:27,RATIO0,95 X ENGINE REVOLUTIONS
411
DRIVE SHAFT27 ZAEHNE I0,95 X N MOTOR, FROM TRANSMISSION 029243 FOR GEAR SET 41:27,RATIO0,95 X ENGINE REVOLUTIONS
411
DRIVE SHAFT27 ZAEHNE I0,95 X N MOTOR, FROM TRANSMISSION 029243 FOR GEAR SET 41:27,RATIO0,95 X ENGINE REVOLUTIONS
413
CYLINDR. ROLLER BEARING FRONT
413
GROOVED BALL BEARING OUTPUT SHAFT
415
CYLINDR. ROLLER BEARING FRONT
415
GROOVED BALL BEARING OUTPUT SHAFT
415
GROOVED BALL BEARING OUTPUT SHAFT
417
THRUST WASHERI0.95 X N MOTOR, FROM TRANSMISSION 029243 FOR GEAR SET 41:27,RATIO0,95 X ENGINE REVOLUTIONS
417
THRUST WASHERI0.95 X N MOTOR, FROM TRANSMISSION 029243 FOR GEAR SET 41:27,RATIO0,95 X ENGINE REVOLUTIONS
419
COVERI0.95 X N MOTOR
419
COVER REAR P.T.O.
419
COVER REAR P.T.O.
419
COVERI0.95 X N MOTOR
421
SEAL RING OIL DISTRIBUTOR BLOCK
421
SEAL RING OIL DISTRIBUTOR BLOCK
421
SEAL RING , Replaced By: A0229974147
421
SEAL RING , Replaced By: A0129979847
421
SEAL RING , Replaced By: A0089975147
422
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
422
SPRING WASHER
423
SCREW BRACKET TO LEFT SIDE MEMBER
423
SCREW , Replaced By: N000933012128
424
COUPLING FLANGE
425
SHIM FLANGE TO TRANSMISSION CASE COVER
427
SEAL RING FLANGE TO TRANSMISSION CASE COVER
427
SEAL RING FLANGE TO TRANSMISSION CASE COVER
427
SEAL RING FLANGE TO TRANSMISSION CASE COVER
427
SEAL RING FLANGE TO TRANSMISSION CASE COVER
428
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
428
SPRING WASHER
430
SCREW BRACKET TO FRAME
432
COVER , Replaced By: A0009977535
432
SCREW PLUG BELL HOUSING
432
PLUG , Replaced By: A3529970032
432
PLUG , Replaced By: A0009977535
432
PLUG , Replaced By: A0009973435
435
GASKET COVER TO P.T.O. CASE
437
COVER
439
SCREW PLUG OIL DRAIN, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
441
SPRING WASHER STEERING COLUMN BRACKET TO CAB
443
SCREW BRACKET TO SIDE MEMBER
445
THRUST WASHER
447
SHIFT LEVER P.T.O. SHIFT LEVER
452
SPRING WASHER , Replaced By: N000137008212
453
SCREW PIPE CLAMP
453
SCREW , Replaced By: N304017008021
455
FLANGE OUTPUT FLANGE,BOTTOM
457
BEARING BRACKET FROM SHIFT LEVER TO P.T.O.
462
SCREW STRAP TO BRACKET
466
SHIFT LEVER
470
BUSHING
471
LOCK RING RELEASE YOKE TO BEARING BRACKET
473
BALL PIVOT BELT TIGHTENER
475
TOOTHED WASHER
477
NUT BRACKET TO SUPPORT AND TO END PIECE
479
PULL ROD SUPPORT TO CONSOLE, TO BE ADAPTED DURING ASSEMBLY
479
PULL ROD , Replaced By: N900331010654
480
NUT BRACKET TO SUPPORT AND TO END PIECE
482
BALL SOCKET BELT TIGHTENER
483
BOOT SHIFT LEVER BEARING COVERING
483
BOOT SHIFT LEVER BEARING COVERING
485
NUT SHIFT LEVER HANDLE TO SHIFT LEVER
485
NUT SHIFT LEVER HANDLE TO SHIFT LEVER
485
NUT , Replaced By: N308673010000
487
HANDLE
487
HANDLE
999
VALVE , Replaced By: A0002600857, +002A0002641271
999
VALVE , Replaced By: A0004291495, +002A3432610090
999
VALVE , Replaced By: A0002600857
999
GEAR (DRIVE GEAR),P.T.O. Z 48
999
VALVE , Replaced By: A0004291495, +002A3432610090
999
VALVE24V,4 237957 IN CASE OF R.H.D.,EXCHANGE BREATHER AND SCREW PLUG AGAINST ONE ANOTHER PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
COVER SHIFTING ROD, WITH AK 6-90 UP TO TRANSMISSION 068147,WITH AK 6-80 UP TO TRANSMISSION 279573
999
TRANSMISSION CASE COVER COUNTERSHAFT,FRONT,279826
999
TRANSMISSION CASE
999
RING AS REQUIRED 7.60 MM,047093
999
RING AS REQUIRED 7.40 MM,047093
999
RING AS REQUIRED 7.20 MM,047093
999
RING AS REQUIRED 7.00 MM,047093
999
RING AS REQUIRED 6.80 MM,047093
999
RING AS REQUIRED 6.40 MM,047093
999
GASKET , ONLY FOR TRANSMISSION HAVING SWIVEL-MOUNTED CYLINDER
999
OIL BAFFLE
999
FOLLOWER
999
RING HALF AS REQUIRED 8.00 MM,047093
999
RING HALF AS REQUIRED 7.80 MM,047093
999
RING HALF , Replaced By: A0002620677
999
RING HALF , Replaced By: A0002620777
999
RING HALF , Replaced By: A0002620877
999
RING HALF , Replaced By: A0002620977
999
RING HALF , Replaced By: A0002621077
999
RING HALF , Replaced By: A0012620530
999
RING HALF AS REQUIRED 6.50 MM,047093
999
RING HALF , Replaced By: A0002621177
999
RING HALF AS REQUIRED 4.05 MM
999
RING HALF AS REQUIRED 6.20 MM,047093
999
RING HALF AS REQUIRED 6.10 MM,047093
999
RING HALF AS REQUIRED 6.00 MM
999
RING HALF AS REQUIRED 6.70 MM,047093
999
RING HALF , Replaced By: A0012621130
999
RING HALF AS REQUIRED 7.10 MM,047093
999
RING HALF AS REQUIRED 7.30 MM,047093
999
RING HALF AS REQUIRED 7.50 MM,047093
999
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
999
CONNECTOR
999
HOSE365 MM
999
MAGNET
999
SHELL TWO-SPEED REAR AXLE CONTROL,4 188089
999
SHELL TWO-SPEED REAR AXLE CONTROL,4 188089
999
NUT , Replaced By: A0029906251
999
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
999
PIN BUSHING , Replaced By: A0075458226
999
BUTTON TWO-SPEED REAR AXLE CONTROL,4 188089
999
CLAMP CABLE HARNESS MOUNTING,4 494992
999
BOOT *** 2.5 MM2
999
TAPERED ROLLER BEARING , UP TO TRANSMISSION 017932
999
CAGE , Replaced By: A0029813510
999
T-FITTING FITTING,5 461950
999
PLUG , Replaced By: A0009979730
999
LOOM TIE , Replaced By: A0009974390
999
LOOM TIE FOR LINES, 10 FROM IDENT NO.631934 20 FROM IDENT NO.671517 ALSO INSTALLED ON 500001-5999994 495577
999
SCREW PLUG OIL FILLING, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
999
RING HALF AS REQUIRED 6.60 MM,047093
999
SWITCH TWO-SPEED REAR AXLE CONTROL,4 188089
999
PIN BUSHING HOUSING 4-POLE
999
CYLINDR. ROLLER BEARING ON THE OUTSIDE
999
CYLINDR. ROLLER BEARING , Replaced By: N005412770009
999
NEEDLE BEARING , UP TO TRANSMISSION 026748
999
NEEDLE BEARING , Replaced By: A0029817510
999
NEEDLE BEARING , Replaced By: A0029813510
999
SEALING CORD , Replaced By: A0119979145
999
WASHER BRACKET TO COVERING
999
WASHER
999
WASHER AS REQUIRED 0.50 MM,279825
999
LOCK AS REQUIRED 2.40 MM
999
LOCK AS REQUIRED 2,55 MM
999
LOCK , Replaced By: A0099947141
999
LOCK AS REQUIRED 2.65 MM
999
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
999
PIN BUSHING HOUSING UNIPOLAR
999
PIN BUSHING HOUSING UNIPOLAR
999
NEEDLE BEARING , Replaced By: A0059810510
999
NEEDLE BEARING , Replaced By: A0002683050
999
NEEDLE BEARING , Replaced By: A0059818010
999
SCREW
999
NUT POTENTIOMETER TO INSTRUMENT PANEL
999
NEEDLE BEARING , Replaced By: A0119811210
999
SOCKET. PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 2,5 MM2
999
LOCK AS REQUIRED 65X2.6 MM
999
NEEDLE BEARING
999
CLAMP WIRE CABLE TO CAB, FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB
999
BEFESTIGUNGSSCHELLE. CLAMP LINES TO ENGINE
999
CLAMP , Replaced By: N072571001035
