Поз.
Артикул
Описание
132
AIR CLEANERFRAM DO BRASIL
132
AIR CLEANER"MANN DO BRASIL", 030-041 FROM IDENT NO.: 679208
134
FILTER BOWLTO 376 090 96 01CICLONIZADOR
136
FILTER ELEMENT
136
FILTER ELEMENTTO 376 090 82 04
138
ADAPTER FITTINGTO 345 094 78 02,345 094 79 02
140
THREADED NIPPLETO 345 094 78 02,345 094 79 02
142
NUT
144
VACUUM BOXTO 345 094 78 02,345 094 79 02
146
VACUUM BOXTO 345 094 80 02,78 02,81 02
148
NUTTO 345 094 79 02,345 094 77 02
150
THREADED UNIONTO 345 094 81 02,80 02,85 02
152
NUTTO 345 094 81 02,80 02,85 02
154
GASKETTO 000 094 11 68,345 094 71 68
156
LOCKTO 345 094 78 02,308 094 76 02
158
SEAL RINGTO 345 094 78 02,345 094 79 02
160
GASKETTO 345 094 78 02
162
NUTTO 345 094 78 02,345 094 79 02
164
FILTER BOWLTO 345 094 80 02,81 02,85 02
166
FASTENERTO 376 090 96 01
168
VALVETO 376 090 96 01
170
FILTER BOWLTO 345 094 78 02,345 094 79 02
172
SEPARATORTO 374 094 00 02
174
CYCLONE PRE-FILTER BOWLTO 345 094 77 02,345 094 78 02
177
BRACKET
177
BRACKETTO 345 094 78 02,345 094 79 02,77 02
180
NUT
182
NUT
184
SCREW CABLE CONNECTOR TO BRACKET
186
SCREW
190
INTAKE PIPE
206
HOSE FROM PICO AIR CLEANER TO INTAKE MANIFOLD AT ENGINE
218
CLAMP. LOOM TIE90-110
218
CLAMP
