Поз.
Артикул
Описание
15
EXHAUST PIPE FRONT
17
PROTECTIVE PLATE , Replaced By: A3834900330
18
SCREWM 6X12
19
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
20
WASHER PLUG SOCKET TO BRACKET
25
FLANGE GASKET FRONT EXHAUST PIPE TO EXHAUST MANIFOLD, ONLY APPLICABLE TO SUPERCHARGING SYSTEM
32
SCREW FRONT EXHAUST PIPE TO EXHAUST MANIFOLD, ONLY APPLICABLE TO SUPERCHARGING SYSTEM
35
NUT CONNECTOR TO EXHAUST MANIFOLD
41
CLAMP SUPPORT TO SIDE MEMBER 75.5 MM
45
SCREW , Replaced By: N304017010002
50
NUT BRACKET TO SIDE MEMBER,XB209706
72
BRACKET BOTTOM
92
SUPPORT TOP
96
SCREW PLUG SOCKET TO FRAME
98
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
106
SCREW PLUG SOCKET TO FRAME
108
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
116
FRONT EXHAUST PIPE FRONT,696639
155
EXHAUST MUFFLER
155
EXHAUST MUFFLER
155
EXHAUST MUFFLER , Replaced By: A3454907101
155
EXHAUST MUFFLER , Replaced By: A3454907101
155
EXHAUST MUFFLER , Replaced By: A3454907101
190
SUPPORT ,588186
192
SCREW LINES TO BRACKET
192
SCREW POWER CYLINDER TO BEARING BRACKET
196
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
205
REAR EXHAUST PIPE REAR, NOT INCLUDED IN RANGE OF DELIVERY OF: 345 490 80 01
208
BRACKET BOTTOM
210
SCREW PLUG SOCKET TO FRAME
214
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
