Поз.
Артикул
Описание
10
PLATE ACCELERATOR PEDAL
35
PAD , 032,033,040,041 UP TO CAB 1806057, 132,133,140,141 UP TO CAB 1800106
40
GUARD PLATE ACCELERATOR PEDAL BEARING
45
COVERING ACCELERATOR PEDAL BEARING
50
PLATE ACCELERATOR PEDAL CONTROL,GB718836
55
PAD ACCELERATOR PEDAL CONTROL,GB718836
60
SCREW FUSE BOX TO APPARATUS PLATE
65
BEARING TUBE ACCELERATOR PEDAL CONTROL,GB718835
65
BEARING TUBE ACCELERATOR PEDAL CONTROL
70
BEARING TUBE ACCELERATOR PEDAL CONTROL,GB718836
75
SCREW CLUTCH TO FLYWHEEL M8X18,4 188090-4 277323
80
LOCK WASHER RAIL TO BATTERY SUPPORT
85
LEVER ,GB718836
90
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
125
LEVER ,718835
125
LEVER , INAPPLICABLE TO SUPERCHARGING SYSTEMGB718835
130
LEVER ,GB718836
135
BALL PIVOT , Replaced By: A3129910120
135
BALL PIVOT LEVER
140
WASHER PULL ROD TO SHIFT LEVER
145
LOCK WASHER RAIL TO BATTERY SUPPORT
150
NUT , Replaced By: N304032008006
255
ROD
260
PULL ROD
265
BALL SOCKET AT CONTROL LEVER
270
NUT
275
SECURING CLIP. CIRCLIP ACCELERATOR CONTROL
520
KNOB WITH SPINDLE, ON CAB 344
520
KNOB WITH SPINDLE, ON CAB 344
520
KNOB , Replaced By: A3523001407
525
BRACKET MANUAL CONTROL, ON CAB 331
535
SCREW SWITCH TO ENGINE
540
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
545
WASHER PLUG SOCKET TO BRACKET
550
GROMMET WIRE CABLE THRU FIRE WALL, ON CAB 331GB718835
555
ROLLER ,GB718836
560
PIN ROLLER TO LEVER,GB718836
565
WASHER PLUG SOCKET TO BRACKET
570
COTTER PIN BATTERY COVER TO 388 540 70 14
575
CLAMP WATER TEMPERATURE GAUGE CABLE TO FIRE WALL
580
SHEET METAL SCREW WIRE CABLE TO CAB
600
GROMMET
600
GROMMET , Replaced By: A3453027091
600
GROMMET , Replaced By: A3453027091
610
CLAMP
635
SCREW CABLE TO FUSE BOX M 6X12
640
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
645
SCREWM 6X12
650
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
655
NUT
999
WASHER , ON SPECIAL REQUEST
999
NUT , UP TO IDENT NO. 4 155516 ALSO INSTALLED ON 500001-521292
999
WASHER , UP TO IDENT NO. 4 155516 ALSO INSTALLED ON 500001-521292
999
GUIDE , FROM IDENT NO. 739256 ALSO INSTALLED ON:500001-599999 UP TO IDENT NO. 4 155516 ALSO INSTALLED ON 500001-521292
