Поз.
Артикул
Описание
15
AIR INTAKE PIPE
15
AIR INTAKE PIPE , Replaced By: A3445207101
16
SCREW PLUG SOCKET TO FRAME
17
WASHER TRAILER PLUG SOCKET TO BRACKET
18
LOCK WASHER RAIL TO BATTERY SUPPORT
45
HOSE
45
HOSE FROM AIR CLEANER TO ENGINE
50
CLAMP
50
CLAMP. LOOM TIE90-110
50
CLAMP100-120
52
LOOM TIE. CLAMP AS REQUIRED
52
LOOM TIE. CLAMP
72
SHIM , 057,058 FROM CHASSIS 487951
72
SHIM , 057,058 UP TO CHASSIS 487950
72
SHIM , Replaced By: A3443170384
80
SCREW , Replaced By: N304017010002
82
SCREW CROSS MEMBER TO SIDE MEMBERS
84
LOCK WASHER , Replaced By: N912004010102
86
WASHER GROUND CABLE
88
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
95
SCREW BEARING BRACKET TO SIDE MEMBER
97
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
99
NUT SPRING BOLT
101
SCREW , Replaced By: N304017010002
103
LOCK WASHER , Replaced By: N912004010102
105
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
110
BRACKET , 057,058 FROM CHASSIS 487951
110
BRACKET , 057,058 UP TO CHASSIS 487950
110
BRACKET , Replaced By: A3445200341
110
BRACKET , Replaced By: A3445200341
130
AIR CLEANER DRY FRAM DO BRASIL
130
AIR CLEANER , Replaced By: A3440948402
130
AIR CLEANER DRY MANN
130
AIR CLEANER , Replaced By: A3440948602
130
AIR CLEANER , Replaced By: A3440940002
135
FILTER ELEMENTTO 376 090 82 04
135
FILTER ELEMENT
139
SCOOPTO 345 094 77 02
143
NUTTO 345 094 79 02,345 094 77 02
154
SCREW BRACKET TO SIDE MEMBER
156
WASHER GROUND CABLE
158
LOCK WASHER , Replaced By: N912004010102
160
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
999
LOCKTO 345 094 78 02,308 094 76 02
999
BRACKETTO 344 094 86 02,345 094 82 02
999
NUT
999
SEAL RINGTO 345 094 78 02,345 094 79 02
999
SEPARATORTO 374 094 00 02
999
CYCLONE PRE-FILTER BOWLTO 345 094 77 02,345 094 78 02
999
SCREW
999
SCREWTO 344 094 82 02,344 094 84 02
999
FASTENERTO 344 094 82 02
999
CLAMPTO 344 094 82 02
999
SCOOPTO 344 094 82 02,344 094 84 02
999
SCOOP , Replaced By: A3440947011
999
FILTER BOWLTO 345 094 78 02,345 094 79 02
999
FILTER BOWLTO 344 094 00 02
999
FILTER BOWLTO 344 094 82 02
999
FILTER BOWL
999
NUTTO 344 094 70 02
999
FILTER BOWLTO 376 090 96 01CICLONIZADOR
999
HOSE FROM PICO AIR CLEANER TO TURBOCHARGER
999
AIR INTAKE PIPE ,672593
999
HOSE
999
VALVETO 376 090 96 01
999
BOTTOM PARTITION
999
NUT
