Поз.
Артикул
Описание
1
CAMSHAFT WITH INJECTION TIMING DEVICE
5
THRUST WASHER CAMSHAFT FIXING, 340.930 FROM ENGINE 085456 ONLY APPLICABLE TO ENGINES WITH CAMSHAFT DRIVEN INJECTION TIMING DEVICE
10
SCREW COVER PLATE TO COVER PLATE
30
VALVE TAPPET REPAIR SIZE III 28.73 MM,28.74 MM
30
VALVE TAPPET REPAIR SIZE II 28.48 MM-28.49 MM
30
VALVE TAPPET REPAIR SIZE I 28.18 MM-28.19 MM
30
VALVE TAPPET STANDARD 27.98 MM,27.99 MM,729031
30
VALVE TAPPET REPAIR SIZE II 28.48 MM-28.49 MM
30
VALVE TAPPET REPAIR SIZE III 28.73 MM - 28.74 MM
30
VALVE TAPPET STANDARD 27.98 MM-27.99 MM
30
VALVE TAPPET REPAIR SIZE I 28.18 MM-28.19 MM
32
PUSH ROD
35
ROCKER ARM LEFT NO.1,NO.3,NO.5,NO.7
35
ROCKER ARMNO. 1, NO. 3, NO. 5, NO. 7
45
BUSHINGTO 366 050 05 33,04 34
45
BUSHINGTO 352 050 06 34,352 050 10 33
53
SPRING LONG,ROCKER ARM SPACING
56
ROCKER ARMNO. 2, NO. 4, NO. 6, NO. 8
56
ROCKER ARMNO.2,NO.4,NO.6,NO.7
59
BUSHINGTO 366 050 05 33,04 34
59
BUSHINGTO 352 050 06 34,352 050 10 33
62
BALL PIN ROCKER ARM
65
NUT
65
NUT , Replaced By: A4229900051
68
ROCKER ARM SPINDLE
71
EXPANSION PLUG LATERAL P.T.O. WITH REVERSE SPEED
74
SPACER TUBE INSIDE
74
OIL PIPE
74
SPACER TUBETO 312 055 05 53
76
SEAL RING
77
SPRINGTO 312 055 05 33
80
SPACER TUBE
80
SPACER TUBE
80
SPACER TUBE OUTSIDE
83
ROCKER ARM BRACKET , Replaced By: A3520550610
83
ROCKER ARM BRACKET OIL SUPPLY NO.1
86
ROCKER ARM BRACKETNO.2,5,6
86
ROCKER ARM BRACKET , Replaced By: A3520550410
89
ROCKER ARM BRACKETNO.3
89
ROCKER ARM BRACKET , Replaced By: A3520550210, +001N000417006001
92
SCREW , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 177596, Replaced By: A3669900104
92
SCREW ROCKER SHAFT TO CYLINDER HEAD
95
SCREW , Replaced By: A0029903804
98
HEADLESS SETSCREW PLANET GEAR, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
101
SPRING
105
SPRING
108
INTAKE VALVE , Replaced By: A3520500026
111
EXHAUST VALVE ,042963
111
EXHAUST VALVE
111
EXHAUST VALVE , Replaced By: A3660500627
111
EXHAUST VALVE , Replaced By: A3660500027
114
WASHER
114
WASHER VALVE SPRING
117
VALVE SPRING
117
VALVE SPRING
120
SPRING RETAINER
123
VALVE COLLET
123
VALVE COLLET
999
PUSH ROD
999
VALVE TAPPET , Replaced By: A3440547301
999
VALVE TAPPET , Replaced By: A3440547201
999
VALVE TAPPET , Replaced By: A3440547101
999
VALVE TAPPET , Replaced By: A3440547001
999
VALVE TAPPET , Replaced By: A3520540801
999
VALVE TAPPET , Replaced By: A3520540701
999
VALVE TAPPET , Replaced By: A3520540601
999
VALVE TAPPET , Replaced By: A3520540501
