Поз.
Артикул
Описание
171
LINE , Replaced By: A3454207028
171
LINE , Replaced By: A3454207028
171
LINE FROM FLUID RESERVOIR TO CONNECTOR 8X0.7 MM, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 588185
172
LINE , Replaced By: A3454203228
172
LINE8X0.7 MM, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 588185
173
LINE , Replaced By: A3454207128
173
LINE , Replaced By: A3454207128
173
LINE FROM FLUID RESERVOIR TO CONNECTOR 8X0.7 MM, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 588185
174
LINE , Replaced By: A3454207428
174
LINE8X0.7 MM, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 588185
184
HOSE , Replaced By: A3099971682
186
LINE , Replaced By: A3454207528
186
LINE FROM MASTER CYLINDER TO FRONT LEFT BRAKE HOSE 6X0.7 MM, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 588185
188
LINE , Replaced By: A3454207628
188
LINE FROM MASTER CYLINDER TO FRONT RIGHT BRAKE HOSE 6X0.7 MM, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 588185
190
UNION SCREW , Replaced By: A0004280072
190
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
214
BRAKE HOSE
214
BRAKE HOSE , USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 588185
222
BRACKET , Replaced By: A3454297640
222
BRACKET COMPRESSED AIR LINE MOUNTING
231
LINE , Replaced By: A3454207828
231
LINE FROM MASTER CYLINDER TO CONNECTOR 6X0.7 MM, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 588185
232
UNION SCREW , Replaced By: A0004280072
232
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
233
CONNECTOR , Replaced By: A0004292736
233
CONNECTOR OIL DELIVERY LINE
233
CONNECTOR
234
LINE , Replaced By: A3454207728
234
LINE FROM CONNECTOR TO BRAKE HOSE AT REAR AXLE 6X0.7 MM, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 588185
249
BRACKET , Replaced By: A3184280240
254
BRAKE HOSE , Replaced By: A0024280735
254
BRAKE HOSE , Replaced By: A0024280735
272
LINE , Replaced By: A3454207338
272
LINE FROM DISTRIBUTOR TO LEFT REAR WHEEL 6X0.7 MM, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 588185
273
LINE , Replaced By: A3454207228
273
LINE FROM DISTRIBUTOR TO RIGHT REAR WHEEL 6X0.7 MM, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 588185
999
NUT BRACKET TO RETARDER
999
HEX. NUT. NUT FUEL TANK TO CONSOLE,167609
999
NUT SPRING BOLT
999
NUT BRAKE ANCHOR PLATE TO REAR AXLE M 12X1.5
999
NUT PULL ROD
999
NUT BRACKET TO SIDE MEMBER
999
NUT FRONT SPRINGS TO FRONT AXLE
999
NUT , 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
999
NUT FRONT WHEEL BRAKE TO STEERING KNUCKLE
999
NUT , Replaced By: N308675012000
999
NUT , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
999
NUT , Replaced By: N000936012005
999
NUT LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
999
SCREW SHOCK ABSORBER TO UPPER BEARING BRACKET,5 261497
999
SCREW REAR CROSS MEMBER AND GUSSET PLATES TO SIDE MEMBERS M 12X30
999
SCREW BRACKET TO FRAME M 12X35
999
SCREW STEERING COLUMN JACKET TUBE TO FLOOR PLATE
999
SCREW CAP TO BRACKET,JB793543 USED WITH AIR BRAKE, FROM CHASSIS 589555
999
GLAND LINE CONNECTION
999
CUTTING RING. GLAND LINE CONNECTION
999
GLAND , Replaced By: A0019901967
999
GLAND LINE CONNECTION
999
GLAND , Replaced By: A0019901167
999
SCREW-IN FITTING OIL LINE CONNECTION
999
SCREW-IN FITTING AT PRESSURE REGULATOR
999
CONNECTION FITTING ,880809
999
CONNECTION FITTING , Replaced By: A0049971772
999
CONNECTION FITTING HIGH PRESSURE LINE TO STEERING
999
CONNECTION FITTING , Replaced By: N003902018002
999
TOOTHED WASHER LINE CONNECTION TO FIRE WALL,684146
999
TOOTHED WASHER AT BRAKE LINE COUPLING
999
RIVET , Replaced By: A3079900197
999
RIVET
999
SEAL RING
999
SEALING RING. SEAL RING ENGINE BREATHING
999
SEAL RINGTO 000 553 03 05,000 553 18 05,
999
SEAL RINGTO 006 997 00 72
999
SEAL RING LINE CONNECTION
999
SEAL RING
999
SEAL RINGTO 345 430 78 01
999
SCREW PLUG RELAY VALVE,CONNECTION "20",RIGHT
999
SCREW PLUG
999
SHEET METAL SCREW BRACKET TO CAB 4,2X13
999
SHEET METAL SCREW BRACKET TO ELECTRICAL APPARATUS COMPARTMENT 4,8X19
999
SCREW VALVE TO STEERING LOCK
999
SCREW BUZZER TO WINDOW LEVEL GIRDER
999
SCREW COMPRESSED AIR LINE MOUNTING
999
SCREW FUSE BOX TO APPARATUS PLATE
999
SCREW CAP TO BRACKET
999
SCREW CABLE TO ALTERNATOR
999
WASHER5,3
999
GREASE NIPPLE PROTECTIVE TUBE
999
YOKE , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
999
YOKE POWER CYLINDER TO EXHAUST SHUNT FLAP
999
SLIP RING TO 18-MM-DIA. COMPRESSED AIR LINES
999
UNION NUT TO 18-MM-DIA. COMPRESSED AIR LINES
999
NUT CHECK VALVE TO AIR RESERVOIR
999
NUT SUCTION LINE TO OIL PUMP
999
FITTING , Replaced By: A0009970171
999
FITTING , Replaced By: A0009907470
999
FITTING , Replaced By: A0009907070
999
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
999
NUT ELECTRONIC ACCELERATOR PEDAL
999
NUT AIR RESERVOIR,CONNECTIONS: "14,21,35"
999
COUNTERSUNK WASHER CAP TO BRACKET,JB793543 USED WITH AIR BRAKE, FROM CHASSIS 589555
999
CLAMPTO 005 420 99 18
999
CLAMP AS REQUIRED
999
PULL ROD FROM BRAKE INTERMEDIATE SHAFT TO BRAKE LEVER AT REAR AXLE, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 588185
999
RING , Replaced By: A0005830296
999
LOCK WASHER RAIL TO BATTERY SUPPORT
999
LOCK WASHERROCKINGER TYP 59 G140,59 G150
999
NUT TWO-WAY VALVE TO BRACKET
999
NUT PUMP TO BRACKET
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT BRACKET TO SIDE MEMBER,XB209706
999
NUT ALTERNATOR TO SUPPORT
999
COMBINATION BOLT ADJUSTING ECCENTRIC TO BRAKE ANCHOR PLATE
999
UNION NUT LINE CONNECTION
999
NUT. UNION NUT LINE CONNECTION
999
UNION NUT LINE CONNECTION, Replaced By: N000000006239
999
UNION NUT LINE CONNECTION
999
UNION NUT LINE MOUNTING
999
UNION NUT BUTT SCREW CONNECTION
999
HOLLOW SCREW
999
HOLLOW SCREW , Replaced By: N915036010108
999
SEAL RING , Replaced By: N007603012121
999
SEAL RING LINE CONNECTION
999
BANJO UNION FROM PARKING BRAKE VALVE,CONNECTION "23",TO FIRE WALL,746633
999
BANJO UNION HEATING CONNECTION,K 169122
999
THRUST RING BUTT SCREW CONNECTION
999
THRUST RING , 10/20 UP TO CHASSIS 4 191895,50/60 UP TO CHASSIS 4 189545
999
CLAMP LINE TO SIDE MEMBER
999
CLAMP COMPRESSED AIR LINE MOUNTING
999
CLAMP ,K 147121, Replaced By: N000000000319
999
CLAMP BATTERY CABLE MOUNTING
999
CLAMP BRAKE LINE TO CAB SIDE MEMBER
999
CLAMP LINE MOUNTING
999
CLAMP BREATHER LINE TO BRACKET
999
CLAMP PIPE LINE TO CONDENSER
999
HOSE FROM T-FITTING TO COMBINATION CYLINDER ON THE RIGHT,CONNECTION: "12"
999
HOSE RIGHT COMBINATION CYLINDER,CONNECTION: "11","12",11X750 MM,B 646985
999
LOCK RING PIN TO BEARING BRACKET, 380.017,080,081,180,181 ONLY FOR SHORT CAB MERCEDES-BENZ
999
LOCK RING
999
LOCK RING DRIVE GEAR
999
LOCK RING
999
SCREW PLUG , Replaced By: N000908022011
999
SCREW BRACKET TO TRANSMISSION CASE
999
SCREW VALVE BODY ASSEMBLY TO TRANSMISSION M 8X55
999
SCREW PRESSURE REGULATOR TO BRACKET M 8X75
999
SCREW , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
999
SCREW (ARTICULATED ROD)
999
SCREW BATTERY POS. CABLE TO BRACKET,PB004444
999
SCREW CLAMP TO BRACKET
999
SCREW
999
SCREW SWITCH TO BRACKET 8X16
999
SCREW POWER CYLINDER TO BEARING BRACKET
999
SCREW COLD START SYSTEM TO BRACKET
999
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
999
SCREW PLUG SOCKET TO FRAME
999
SCREW LINES TO BRACKET
999
SCREW DAMPING PAD TO SUPPORT M 8X45,B 884219
999
SCREW , Replaced By: N304017010002
999
SCREW , Replaced By: N304017010040
999
SCREW WATER SEPARATOR
999
SCREW CROSS MEMBER TO SIDE MEMBERS
999
SCREW COLD START SYSTEM TO BRACKET
999
SCREW BRACKET TO SIDE MEMBER
999
NUT MODULE TO HOUSING
999
NUT TACHOGRAPH TO BRACKET
999
NUT
999
NUT LEVER TO SHIFTING SHAFT
999
NUT , Replaced By: N304032008006
999
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
999
EXPANSION PLUG
999
NUT ,100570
999
HEADLESS SETSCREW
999
SPRING WASHER CAB FLOOR
999
LOCK WASHER SUPPORT TO SIDE MEMBER
999
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
999
LOCK WASHER , Replaced By: N912004010102
999
LOCK WASHER DELIVERY AND SUCTION LINES TO PIPE CLAMP,1401150112256208
999
LOCK WASHER CLUTCH TO FLYWHEEL
999
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
999
LOCK WASHER PLUG SOCKET
999
WASHER
999
WASHER SUPPORT TO FRAME,D 127794
999
WASHER GROUND CABLE
999
WASHER TRAILER PLUG SOCKET TO BRACKET
999
WASHER PLUG SOCKET TO BRACKET
999
WASHER FUSE TO FUSE BOX
999
WASHER REDUCTION GEARING TO BRACKET
999
COTTER PIN STRAP TO SUPPORT
999
COTTER PIN
999
COTTER PIN , 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
999
COTTER PIN
999
SCREW SHIFT CASE TO SLOTTED GATE
999
ELBOW FITTING DIAPHRAGM CYLINDER,CONNECTION: "1,11"
999
BRAKE LINING , Replaced By: A3454237010
999
BRAKE LINING REPAIR SIZE II 17.7 MM, NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT FOR THE NEW PART NO.,SEE STANDARD VERSION
999
BRAKE LINING REPAIR SIZE I 16.7 MM, NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT FOR THE NEW PART NO.,SEE STANDARD VERSION
999
BRAKE LINING STANDARD 15.7 MM, NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT FOR THE NEW PART NO.,SEE STANDARD VERSION
999
BRAKE LINING , Replaced By: A3454217210
999
BRAKE LINING , Replaced By: A3454217110
