Поз.
Артикул
Описание
5
PRESSURE REGULATORWABCO
7
REPAIR KIT , Replaced By: A0004301107
9
REPAIR KIT , Replaced By: A0004301407
16
ELBOW FITTING
18
NUT CHECK VALVE TO AIR RESERVOIR
20
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
20
THRUST RING CHECK VALVE TO AIR RESERVOIR
24
O-RING CHECK VALVE TO AIR RESERVOIR
29
SEAL RING LINE CONNECTION
34
FITTING SHUTTLE VALVE,CONNECTION: "20"
34
FITTING , Replaced By: A0019972372
35
THRUST RING BUTT SCREW CONNECTION
37
SEAL RING
39
LINE FROM PRESSURE REGULATOR TO FITTING 15X1.5 MM
39
LINE FROM PRESSURE REGULATOR TO FITTING 15X1.5 MM
42
SCREW VALVE BODY ASSEMBLY TO TRANSMISSION M 8X55
42
SCREW PRESSURE REGULATOR TO BRACKET M 8X75
44
LOCK WASHER RAIL TO BATTERY SUPPORT
46
NUT LEVER TO SHIFTING SHAFT
49
LINE FROM AIR COMPRESSOR TO PRESSURE REGULATOR 18X1.5 MM
49
LINE18X1.5 MM,511033
49
LINE FROM AIR COMPRESSOR TO TIRE INFLATOR CYLINDER 18X1.5 MM,486598
52
LINE FROM PRESSURE REGULATOR TO AIR RESERVOIR
52
LINE FROM PRESSURE REGULATOR TO AIR RESERVOIR 15X1.5 MM
52
LINE FROM PRESSURE REGULATOR TO AIR RESERVOIR
52
LINE FROM PRESSURE REGULATOR TO AIR RESERVOIR 15X1.5 MM
52
LINE FROM PRESSURE REGULATOR TO AIR RESERVOIR 15X1.5 MM
52
LINE FROM PRESSURE REGULATOR TO AIR RESERVOIR 15X1.5 MM
54
LINE ELBOW FITTING TO PRESSURE REGULATOR
54
LINE FROM DOUBLE FITTING TO PRESSURE REGULATOR 18X1.5 MM
59
FITTING AIR RESERVOIR,CONNECTION: "2"
59
FITTING AIR RESERVOIR,CONNECTION: "13"
62
LINE AT PRESSURE REGULATOR 15X1.5 MM
64
THRUST RING BUTT SCREW CONNECTION
69
SEAL RING , Replaced By: N007603012121
74
ELBOW FITTING ANTI-FREEZE DEVICE,CONNECTION: "10", BUTT CONNECTION
74
FITTING
79
BRACKET TIRE INFLATOR CYLINDER
83
SCREW PRESSURE REGULATOR TO BRACKET M 8X75
87
NUT LEVER TO SHIFTING SHAFT
90
SCREW LINES TO BRACKET
93
NUT LEVER TO SHIFTING SHAFT
999
UNION NUT LINE CONNECTION, Replaced By: N000000006239
999
CONNECTION FITTING , Replaced By: A0049971772
999
CONNECTION FITTING , Replaced By: A0039979172
999
GLAND , Replaced By: A0019901967
999
LINE , Replaced By: A3084200126
999
REPAIR KIT IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.: 001 586 43 43, TO 001 431 22 06
999
PRESSURE REGULATOR"WABCO",486597
999
LINE DOUBLE LEVER TO THRUST SHACKLE, USED WITH AIR BRAKE,FROM CHASSIS 588186
999
LINE FROM FITTING TO FOUR-CIRCUIT PROTECTIVE VALVE,CONNECTION: 12X1 MM,"1", USED WITH AIR BRAKE,FROM CHASSIS 588186
999
AIR CLEANER. TIRE INFLATOR CYLINDER ,511032
999
LINE FROM PRESSURE REGULATOR TO DOUBLE FITTING 15X1.5 MM,511032
999
LINE FROM AIR RESERVOIR TO CONNECTOR
999
LINE FROM AIR COMPRESSOR TO PRESSURE REGULATOR 18X1.5 MM,511032
999
LINE FROM FITTING TO FOUR-CIRCUIT PROTECTIVE VALVE,CONNECTION: 12X1 MM
999
LINE FROM AIR COMPRESSOR TO TIRE INFLATOR CYLINDER 18X1.5 MM,486597
999
LINE FROM AIR COMPRESSOR TO TIRE INFLATOR CYLINDER 18X1.5 MM,D 335217486597
999
LINE FROM PRESSURE REGULATOR TO FITTING 15X1.5 MM
999
FITTING BRAKE HOSE TO COMPRESSED AIR LINE
999
REPAIR KIT VALVE KIT WABCO,5 148812
999
ELBOW FITTING AT PRESSURE REGULATOR,462277
999
VALVE , Replaced By: A0014316906
999
VALVE. PRESSURE REGULATOR ,FB486597
999
PRESSURE REGULATOR
999
LINE15X1.5 MM, LENGTH AVAILABLE 3000 MM
999
LINE18X1.5 MM, LENGTH AVAILABLE 4000 MM
