Поз.
Артикул
Описание
7
FUEL TANK LESS SENDER UNIT
7
FUEL TANK , Replaced By: A3444709101
7
FUEL TANK LESS SENDER UNIT
12
SUPPORT
17
SUPPORT
19
SUPPORT
21
WASHER IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.: 360 990 18 40
22
BRACKET
27
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
32
SCREW BATTERY POS. CABLE TO BRACKET,PB004444
37
CLAMP LINE MOUNTING
42
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
47
SCREW CABLE TO ALTERNATOR
52
NUT
57
LINE FROM FUEL TANK TO RUBBER HOSE
57
LINE FEED 2600 MM
62
LINE FROM RUBBER HOSE TO FUEL TANK
67
LINE RETURN 1800 M
67
LINE FROM RUBBER HOSE TO FUEL TANK
72
LINE470 MM
72
LINE FROM RUBBER HOSE I TO RUBBER HOSE II
77
LINE RETURN LINE
82
LINE LEAK LINE
87
HOSE
97
CLAMP CONNECTION OF FUEL LINES ONE BELOW THE OTHER
102
GROMMET FUEL-GAUGE-SENDER-UNIT CABLE THRU SIDE MEMBER
999
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
999
SUPPORT WITH SEAL CONE
999
SHIM CONSOLE TO SIDE MEMBER,KB860814
999
LINE FROM HOSE TO TANK
999
SUPPORT FUEL TANK,659794
999
LINE FROM TANK TO HOSE
999
LINE FROM HOSE TO TANK
999
LINE FROM RUBBER HOSE TO FUEL TANK
999
SUPPORT
999
SUPPORT
999
LINE FROM FUEL TANK TO RUBBER HOSE,FB689884
999
LINE FROM RUBBER HOSE TO FUEL TANK,FB689884
