Поз.
Артикул
Описание
95
LINE (FUEL LINE),647770
95
LINE (FUEL LINE),647770
95
LINE (FUEL LINE),647769
95
LINE (FUEL LINE)
95
LINE (FUEL LINE)
95
LINE (FUEL LINE),647770
95
LINE (FUEL LINE),647769
95
LINE (FUEL LINE),647769
155
LINE FUEL RETURN LINE
155
LINE FUEL RETURN LINE
155
LINE FUEL RETURN LINE,647769
155
LINE FUEL RETURN LINE
155
LINE FUEL RETURN LINE,647770
155
LINE FUEL RETURN LINE,647769
155
LINE FUEL RETURN LINE,647769
155
LINE FUEL RETURN LINE
175
LINE LEAK RETURN
175
LINE LEAK RETURN
175
LINE LEAK RETURN,647769
175
LINE LEAK RETURN
175
LINE LEAK RETURN
175
LINE ,647770
175
LINE LEAK RETURN
175
LINE LEAK RETURN
205
BRACKET FUEL LINES
210
BRACKET FUEL LINE
225
BRACKET PULL ROD TO SUPPORT,5 352764 TO BE ADAPTED DURING ASSEMBLY
225
SHIM , Replaced By: A3184924841
230
SCREW POWER CYLINDER TO BEARING BRACKET
230
SCREW , Replaced By: N304017010002
235
WASHER GROUND CABLE
240
LOCK WASHER , Replaced By: N912004010102
245
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
245
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
250
CLAMP LINE MOUNTING
250
CLAMP LINE MOUNTING
265
SCREW CLAMP TO BRACKET
265
SCREW CAP TO BRACKET
275
SCREW , Replaced By: N304017010002
280
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
285
LOCK WASHER , Replaced By: N912004010102
290
WASHER GROUND CABLE
295
NUT PUMP TO BRACKET
295
NUT
305
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
310
RIVET CROSS MEMBER TO SIDE MEMBERS 14X32MM, 647770
310
RIVET10X28 MM
310
RIVET CROSS MEMBER TO SIDE MEMBERS 14X32MM, 647770
310
RIVET10X20 MM
310
RIVET10X20 MM
310
RIVET , Replaced By: N910005010008
325
SCREW POWER CYLINDER TO BEARING BRACKET
330
HOSE
335
SCREW BUFFER TO BRACKET
340
NUT BRACKET TO SIDE MEMBER,XB209706
999
BANJO UNION , Replaced By: N915052008019
999
CLAMP FUEL LINES TO BRACKET
999
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
999
DISTRIBUTOR LEAK LINE,659794
999
HOSE , Replaced By: A3449977582
999
CONNECTOR
999
SUPPORT WITH SEAL CONE
999
SHIM CONSOLE TO SIDE MEMBER,KB860814
999
RUBBER STRIP , Replaced By: A3459837391
999
BRACKET AT CROSS MEMBER
999
RISING PIPE ,659794
999
SUPPORT FUEL TANK,659794
999
FUEL TANK LESS SENDER UNIT
999
SHIM CONSOLE TO SIDE MEMBER
999
WASHER BATTERY CASE
999
LOOM TIE , Replaced By: A3459977390
999
STRAP FUEL TANK
999
LINE FROM FUEL TANK TO RUBBER HOSE,689884
999
LINE FROM RUBBER HOSE TO FUEL TANK,689884
999
LINE LEAK RETURN, FROM FITTING TO FUEL TANK
999
CARDBOARD FUEL TANK TO SUPPORT, 344.058 UP TO SHASSIS 659793
999
LINE FUEL LINE TO CYLINDER HEAD,689885
999
PAD FUEL TANK TO CONSOLE, ORDER BY THE METER
999
LINE
