Поз.
Артикул
Описание
15
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
20
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
22
WASHER BRACKET TO LEFT SIDE MEMBER
22
WASHER , Replaced By: N009021008213
35
SUPPORT WATER SEPARATOR
40
SCREW END PIECE TO EXHAUST PIPE M 10X25
45
NUT , Replaced By: N910113010000
45
NUT STRAP TO BRACKET
170
BRAKE VALVE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0034313405
170
BRAKE VALVE , Replaced By: A0024314805
170
BRAKE VALVE (TRAILER CONTROL VALVE) WABCO,4 412021 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
170
BRAKE VALVE (TRAILER CONTROL VALVE) BOSCH,4 412021 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
170
BRAKE VALVE (TRAILER CONTROL VALVE) KNORR, IN CASE OF NOISE MEASUREMENTS,PLEASE REFER TO WORKING INSTRUCTION PRIOR TO ORDERING PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
170
BRAKE VALVE (TRAILER CONTROL VALVE) GRAU,4 412021
170
BRAKE VALVEWABCO, IN CASE OF NOISE MEASUREMENTS,PLEASE REFER TO WORKING INSTRUCTION PRIOR TO ORDERING
170
BRAKE VALVE (TRAILER CONTROL VALVE) KNORR,4 412021
170
BRAKE VALVEGRAU, IN CASE OF NOISE MEASUREMENTS,PLEASE REFER TO WORKING INSTRUCTION PRIOR TO ORDERING
170
BRAKE VALVE , IN CASE OF NOISE MEASUREMENTS,PLEASE REFER TO WORKING INSTRUCTION PRIOR TO ORDERING, Replaced By: A0024314005
175
VALVE SEATTO 001 431 74 05,GRAU 355 029 001
178
VALVE SEATTO GRAU
181
GASKET34X2X6 MM,GRAU
185
SEAL RING64.77X2.62,TO GRAU
190
SEAL RING18X2.5,TO GRAU
195
SEAL RING44.2X3,TO GRAU
200
SEAL RING30X2,TO GRAU
205
SEAL RING7X1.5,TO GRAU
210
SEAL RING21.3X2.4 TO 001 431 74 05,
215
SEAL RING90X3,TO GRAU
220
SEAL RING100X3,TO GRAU
225
SEAL RING39.2X3 TO 001 431 74 05,
230
SEAL RING9X1.5,TO GRAU
235
SEAL RING23.47X2.62,TO GRAU
240
SEAL RING22.3X2.4 MM,GRAU
245
SEAL RINGTO GRAU
250
GASKET KIT SEAL RING TO 001 431 67 05,BOSCH 061 214
255
REPAIR KIT BLEEDER VALVE TO 001 431 67 05,BOSCH
255
REPAIR KITTO KNORR
255
REPAIR KIT VALVE SEAT KNORR
255
REPAIR KIT , Replaced By: A0004301109
255
REPAIR KITTO 001 431 67 05, BOSCH 061 010
255
REPAIR KIT VALVE DISC TO 001 431 67 05,BOSCH 061 214
255
REPAIR KIT , Replaced By: A0014304760
255
REPAIR KIT , Replaced By: A0024301860
255
REPAIR KITTO WABCO
255
REPAIR KITTO GRAU
260
BRACKET TRAILER CONTROL VALVE
265
NUT STRAP TO BRACKET
270
SCREW SUPPORT TO FENDER
270
SCREW , Replaced By: N304017008018
275
NUT STRAP TO BRACKET
280
HOLLOW SCREW LINE TO OIL RADIATOR
285
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
290
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
295
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
300
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
305
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
310
BRAKE VALVE (TRAILER CONTROL VALVE), PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
310
BRAKE VALVE (TRAILER CONTROL VALVE) "BOSCH"
313
REPAIR KIT TRAILER CONTROL VALVE TO 001 431 52 05, WABCO
313
REPAIR KIT , Replaced By: A0014306160
313
REPAIR KIT TRAILER CONTROL VALVE TO 001 431 46 05,BOSCH
316
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
319
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
322
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0024299544
322
VALVE TWO-WAY VOSS
331
BRACKET
331
BRACKET TRAILER CONTROL VALVE TO BRACKET
334
NUT SPRING BOLT
337
SCREW TAIL PIPE BRACKET
340
NUT STRAP TO BRACKET
342
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
345
O-RING CHECK VALVE TO AIR RESERVOIR
350
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
350
THRUST RING CHECK VALVE TO AIR RESERVOIR
355
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
360
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
365
T-FITTING
370
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
375
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
380
O-RING CHECK VALVE TO AIR RESERVOIR
385
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
385
THRUST RING CHECK VALVE TO AIR RESERVOIR
390
NUT CHECK VALVE TO AIR RESERVOIR
400
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
405
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
410
O-RING CHECK VALVE TO AIR RESERVOIR
415
THRUST RING CHECK VALVE TO AIR RESERVOIR
415
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
420
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
425
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
430
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
435
O-RING CHECK VALVE TO AIR RESERVOIR
440
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
440
THRUST RING CHECK VALVE TO AIR RESERVOIR
445
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
450
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
520
FITTING BRAKE LINE COUPLING TO BRACKET
520
FITTING SHUTTLE VALVE
530
NUT BRACKET TO SIDE MEMBER
535
TEST CONNECTION
535
TEST CONNECTION BULKHEAD FITTING
535
TEST CONNECTION , Replaced By: A0004312931
535
TEST CONNECTION , Replaced By: A0004313031
999
GASKETTO 003 429 22 44
999
SEAL RINGTO 000 429 75 30
999
VALVE CONEBOSCH
999
COVERTO 000 429 48 30
999
VALVE BODYTO 002 429 95 44
999
COVERWABCO
999
HANDLETO 001 430 17 81,KNORR
999
REPAIR KIT PARKING BRAKE TO 001 430 16 81
999
LEVER TOOTHED
999
PISTONVOSS
999
COVERTO 000 429 16 30,BOSCH
999
SPRING CAPSULETO 000 429 16 30
999
NUTTO 000 429 16 30
999
VALVE PARTTO 000 429 16 30
999
VALVE TAPPETTO 000 429 16 30
999
VALVE DISCTO 000 429 48 30
999
SPRINGTO 000 429 16 30
999
PROTECTIVE CAPKNORR
999
REPAIR KITWABCO
999
BALLTO 003 429 22 44
999
REPAIR KIT , Replaced By: A0034303281
999
SEAL RING"GRAU"
