Поз.
Артикул
Описание
100
SCREW CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP. M 5X35
100
SCREW , Replaced By: N007985005532
100
SCREW TRAILER PLUG SOCKET TO SUPPORT
100
SCREW REDUCTION GEARING
105
LOCK WASHER BRACKET TO STEERING COLUMN END
110
NUT IN CASE OF SUBSEQUENT INSTALLATION
110
NUT , Replaced By: N304032005005
115
SCREW LICENSE PLATE TO BRACKET
115
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
115
SCREW , Replaced By: N304017008027
120
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
120
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
125
NUT BALL PIVOT TO LEVER
125
NUT COVER PLATE
125
NUT
175
ELECTRIC CABLE FROM PLUG CONNECTION TO STOP LIGHT SWITCH
180
ELECTRIC CABLE TO OIL PRESSURE SWITCH,TEMPERATURE SENDER UNIT,EXHAUST BRAKE
190
PLUG SOCKETM 30 X 1, 10/20 UP TO CHASSIS 4 411810,50/60 UP TO CHASSIS 4 414810
190
PLUG SOCKETM 30 X 1, 10/20 UP TO CHASSIS 4 411810,50/60 UP TO CHASSIS 4 414810
195
PIN BUSHING HOUSING. PLUG HOUSING FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH
195
PIN BUSHING HOUSING BIPOLAR
200
SOCKET. PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 2,5 MM2
200
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
200
SOCKET. PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 2,5 MM2
200
PIN BUSHING , Replaced By: A0075458226
205
PLUG HOUSING 4-POLE
210
PLUG HOUSING 8-POLE
215
PLUG LESS DETENT,BUT WITH CATCH FOR HOUSING 2.5 MM2
215
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
215
PLUG LESS DETENT,BUT WITH CATCH FOR HOUSING 2.5 MM2
220
PIN BUSHING HOUSING 4-POLE
225
PLUG SOCKET WITH TRAILER PLUG SOCKET 12 V
225
PLUG SOCKET WITH TRAILER PLUG SOCKET 12 V
225
PLUG SOCKET , Replaced By: A6685400581
225
ELECTRIC CABLE , Replaced By: A3095400681
225
CABLE HARNESS , Replaced By: A3875400081
225
CABLE HARNESS , Replaced By: A3875400207
225
CABLE HARNESS , Replaced By: A3095400681
225
CABLE HARNESS , Replaced By: A3875400107
225
CABLE HARNESS WITH 7-POLE TRAILER PLUG SOCKET 12 V
230
GROMMET LINE THRU FRAME
999
RELAYTO 001 545 07 18
999
SWITCH EXHAUST BRAKE
999
SWITCH , Replaced By: A0005456009
999
GROMMET TO PLUG THE BORES
999
CABLE CONNECTOR , FROM CHASSIS:108.016 050831 108.018 053598 108.019 054235
999
CABLE CONNECTOR , Replaced By: A0015463341, +001A0005460283
999
CABLE CONNECTOR , Replaced By: A0015463341, +001A0105456728
999
CLAMP , Replaced By: N916016020201
999
CLAMP , Replaced By: N916016015202
999
RUBBER BUFFER TO PLUG THE FREE CONNECTIONS
999
RUBBER BUFFER
999
BRACKET , 355,365 UP TO CHASSIS 690917
999
ELECTRIC CABLE FROM FRONT CABLE CONNECTOR TO REAR CABLE CONNECTOR
999
ELECTRIC CABLE FROM FRONT CABLE CONNECTOR TO REAR CABLE CONNECTOR
999
ELECTRIC CABLE FROM FRONT CABLE CONNECTOR TO REAR CABLE CONNECTOR
999
BRACKET TRAILER PLUG SOCKET
999
ELECTRIC CABLE FROM FRONT CABLE CONNECTOR TO REAR CABLE CONNECTOR
999
BRACKET JUNCTION BOX
999
BRACKET TAIL LAMP,5 453766
999
BRACKET TAIL LAMP,5 453766
999
BRACKET REFLECTOR
999
NAME PLATE
999
ELECTRIC CABLE FROM FRONT CABLE CONNECTOR TO REAR CABLE CONNECTOR
999
SHEET METAL SCREW
