Поз.
Артикул
Описание
8
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
8
PLASTIC PIPE RISING PIPE 4X6 MM
12
SLEEVE LEAK LINE
12
BUSHING , Replaced By: N915062004000
16
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
31
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
43
UNION NUT LINE CONNECTION
43
UNION NUT , Replaced By: N915017008100
47
GLAND LINE CONNECTION
73
FITTING , Replaced By: A0039979972
73
FITTING
77
SEAL RING FUEL LINE TO FEED PUMP
79
BRACKET AT FRAME
83
BRACKET AT FRAME
180
BRAKE VALVE , THE OLD PART MUST NO LONGER BE INSTALLED PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0034313505
180
BRAKE VALVE TRAILER CONTROL VALVE WABCO,4 375193
180
BRAKE VALVE , Replaced By: A0014313705
180
BRAKE VALVE TRAILER CONTROL VALVE BOSCH,4 375193 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
184
REPAIR KIT , Replaced By: A0024306581
186
REPAIR KIT , Replaced By: A0004304606
186
BRAKE VALVE SEAL RING TO 001 431 18 05,4 412020
205
NUT PUMP TO BRACKET
205
NUT , Replaced By: N913004006001
215
FITTING , Replaced By: A0029979572
215
FITTING RELAY VALVE,CONNECTION: "40",5 359430
218
SEALING RING. SEAL RING DELIVERY LINE TO PUMP
218
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
224
T-FITTING RELAY VALVE,CONNECTION: "20"
224
T-FITTING
228
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
232
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
236
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
240
FITTING ,4 667210
248
VALVE ,4 412020
253
REPAIR KIT ,4 412020
257
FITTING ,4 412020
263
SEAL RING INJECTION PUMP
263
SEAL RINGTO 000 553 03 05,000 553 18 05,
267
HOLLOW SCREW PNEUMATIC AND HYDRAULIC CYLINDERS, CONNECTION: "21,22"
267
HOLLOW SCREW LINE CONNECTION
271
SEAL RING PNEUMATIC VALVE
271
SEAL RING , Replaced By: N007603010110
275
BRACKET ,4 412020
279
SCREW
283
NUT TWO-WAY VALVE TO BRACKET
287
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3874300710
287
BRACKET TRAILER CONTROL VALVE
290
SCREW , Replaced By: N304017008034
290
SCREW BRACKET TO CROSS CONNECTION STRUT
293
NUT , Replaced By: N913004008001
293
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
300
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
300
NUT , Replaced By: N913004008001
309
VALVE PARKING BRAKE VALVE WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
318
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
318
HOSE , Replaced By: A0009872827
321
SLEEVE LINE CONNECTION
321
BUSHING , Replaced By: N915062009000
323
SEAL CONE LINE CONNECTION
323
GLAND , Replaced By: A0019901967
327
UNION NUT LINE CONNECTION, Replaced By: N000000006239
327
UNION NUT , Replaced By: N915017012100
327
UNION NUT LINE CONNECTION
370
BRAKE LINE COUPLING SUPPLY, RED
370
BRAKE LINE COUPLING , Replaced By: A0004297830
370
BRAKE LINE COUPLING SUPPLY, RED
370
BRAKE LINE COUPLING SUPPLY, RED
370
BRAKE LINE COUPLING SUPPLY, RED
374
BRAKE LINE COUPLING BRAKE,YELLOW BOSCH
374
BRAKE LINE COUPLING BRAKE,YELLOW GRAU
374
BRAKE LINE COUPLING BRAKE,YELLOW KNORR
374
BRAKE LINE COUPLING BRAKE,YELLOW WESTINGHOUSE
374
BRAKE LINE COUPLING , Replaced By: A0004297930
384
COVERTO 000 429 51 30,4 434235
388
SEAL RING"WABCO"
391
GROOVED PINTO 000 429 51 30,4 434235
398
COVERTO 000 429 49 30
401
REPAIR KIT , TO 000 429 49 304 434235
408
FITTING BRAKE LINE COUPLING TO BRACKET
412
NUT BRACKET TO SIDE MEMBER
416
SEALING RING. SEAL RING DELIVERY LINE TO PUMP
416
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
COVER"WABCO", NOT USED
999
COVER SUPPLY, RED "WABCO"
999
SEAL RING , Replaced By: A0004296930
999
SEAL RING , Replaced By: A0004292184
999
BRAKE LINE COUPLINGTO 000 429 38 30
999
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE BOSCH
999
REPAIR KIT"KNORR"
999
VALVE , TO BE EXHAUSTED UP TO CHASSIS 4 230076, Replaced By: A0004308581
999
REPAIR KITTO 000 430 57 81,43 81,WABCO,0020,0120
999
T-FITTING LUBRICATING LINE TO DISTRIBUTOR
999
SPRING , Replaced By: A0009935205
999
SPRINGBOSCH,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
999
VALVE , Replaced By: A0024297244
999
VALVE (OVERFLOW VALVE),REAR CARRIAGE SECONDARY CONSUMING UNITS "WABCO"
999
VALVE , Replaced By: A0024297244
999
VALVE OVERFLOW VALVE
999
CUPTO 002 431 04 06,BOSCH
999
REPAIR KITTO 001 429 52 44
999
REPAIR KITBOSCH
999
REPAIR KITTO 000 429 37 30
999
REPAIR KITTO 001 431 34 05,4 375193
999
SEAL RINGTO 001 431 37 05,4 375193
999
FITTING , Replaced By: A0039978972
999
LOOM TIE LINE MOUNTING 280 MM
999
LOOM TIE LINE MOUNTING
999
FITTING SPRING LOAD ACCUMULATOR CYLINDER,4 412126
999
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
999
VALVE OVERFLOW VALVE WITH RETURN FLOW GRAU
999
VALVE (OVERFLOW VALVE),4 9119185 116581
999
REPAIR KIT VALVE KIT TO 001 431 37 05,4 375193
999
REPAIR KITTO 001 431 37 05,4 375193
999
REPAIR KITTO 000 429 63 30
999
REPAIR KIT BOOT TO 001 431 38 06,BOSCH, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
REPAIR KIT BOOT TO 001 431 15 06,BOSCH
999
REPAIR KITTO 000 429 78 30,4 434236
999
REPAIR KIT SEAL RING TO 001 431 15 06,BOSCH
999
REPAIR KITTO 001 431 48 05,4 375193
999
FITTING (PARTS KIT),LINE RUPTURE
999
FITTING DELIVERY LINE TO PUMP
999
FITTING ,4 412020
999
GASKET KIT SEAL RING TO 001 431 58 06,BOSCH
999
FITTING , Replaced By: A0029905971
999
SEAL RINGTO 000 429 38 30
999
SEAL RING"GRAU"
999
SEAL RING18.72X2.62 MM,WABCO,002 0,012 0
999
BRACKET , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 493018, Replaced By: A3812950440
999
PLUG EXHAUST BRAKE VALVE, CONNECTION: "20"
999
BRACKET , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3872950440
999
LINE FROM PRESSURE REGULATOR TO SLIDE, LENGTH AVAILABLE 3000 MM
999
LINE , Replaced By: A3434293608, +001A0009973873, +001N003861015004
999
BRACKET LEFT
999
BRACKET RIGHT
999
BRACKET , Replaced By: A3812950440
999
CLAMP , Replaced By: N916016008200
999
CLAMP , Replaced By: A3604300143
999
CLAMP LINE MOUNTING
999
CLAMP , Replaced By: A6739950001
999
BRACKET COMPRESSED AIR LINE TO FOUR-CIRCUIT PROTECTIVE VALVE,5 720506
999
BRACKET EXHAUST PIPE SUSPENSION
999
CLAMP DELIVERY AND SUCTION LINES TO STEERING
999
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
999
SCREW CLAMP MOUNTING M 6X16
999
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
LOCK RINGTO 001 431 37 05,4 375193
999
LOCK RING52X2 MM
999
SCREW CAB FLOOR COVERING M 6X25
999
SCREW , Replaced By: N304017010002
999
CONNECTION FITTING ,880809
999
SCREW , Replaced By: N000000001146
999
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
999
FITTING , Replaced By: A0009970171
999
FITTING , Replaced By: A0009907070
999
SCREW BRACKET TO SIDE MEMBER
999
RIVET12X58 MM, TO BE ADAPTED DURING ASSEMBLY
999
CLAMP ,K 147121, Replaced By: N000000000319
