Поз.
Артикул
Описание
14
TANK ,617873
17
VALVE
20
VALVE HOUSING
23
GASKET
26
SCREW 3/2-WAY VALVE TO BRACKET
29
LOCK WASHER PLUG SOCKET
32
NUT TACHOGRAPH TO BRACKET
35
HOSE PARKING BRAKE VALVE
38
CLAMP FLEXIBLE SHAFT
41
SHEET METAL SCREW BRACKET TO CAB 4,2X13
47
RADIATOR CAP
50
SUPPORT EXPANSION TANK,617873
53
SUPPORT EXPANSION TANK
56
STRAP EXPANSION TANK,617873
59
STRAP EXPANSION TANK, FROM IDENT NO. 680089
62
SCREW PLUG SOCKET TO FRAME
65
WASHER BRACKET TO CAB REAR PANEL
68
LOCK WASHER RAIL TO BATTERY SUPPORT
71
SHIM EXPANSION TANK, UP TO IDENT NO. 680088
74
WASHER , Replaced By: N009021006208
77
NUT
80
PIN ROLLER TO LEVER,GB718836
83
COTTER PIN BRACKET TO BATTERY CASE
86
WASHER PLUG SOCKET TO BRACKET
89
NUT
92
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
95
PANELLING ,617873
95
PANELLING
98
LOCK WASHER RAIL TO BATTERY SUPPORT
101
SCREW
101
SCREW PLUG SOCKET TO FRAME
104
WASHER TRAILER PLUG SOCKET TO BRACKET
107
NUT , Replaced By: N304032008006
113
SUPPORT EXPANSION TANK,617873
113
SUPPORT EXPANSION TANK, FROM IDENT NO. 680089
131
BRACKET SUPPORT TO SIDE MEMBER, UP TO IDENT NO. 680088
131
BRACKET SUPPORT TO SIDE MEMBER, FROM IDENT NO. 680089
134
BRACKET SUPPORT TO SIDE MEMBER,617873
134
BRACKET SUPPORT TO SIDE MEMBER, FROM IDENT NO. 680089
137
SCREW BRACKET TO DISC WHEEL M 8X16,D 315831
140
WASHER A 8,4 DIN 9021. WASHER MOUNTING TO SUBSTRUCTURE
143
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
143
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
146
LOCK WASHER RAIL TO BATTERY SUPPORT
999
HOSE , Replaced By: N900271028028, +001A3505017020, +001A3505017024, +001A3505017182, +001A3459957101, +001N000933008023, +001N913004008000
999
HOSE , ORDER BY THE METER617872
999
HOSE , Replaced By: A3505017282
999
HOSE
999
BRACKET , Replaced By: A3505047640
999
SUPPORT RADIATOR MOUNTING,617873
999
BRACKET , Replaced By: A3505047540
999
SUPPORT EXPANSION TANK,617872
999
RADIATOR STRUT , Replaced By: A3505007745
999
RADIATOR STRUT , Replaced By: A3505007645
999
CLAMP , Replaced By: A0019972590
999
SPACER TUBE , Replaced By: A3199910540
999
GASKET
999
VALVE
