Поз.
Артикул
Описание
10
BRACKET , Replaced By: A3464296040
20
SCREW POWER CYLINDER TO BEARING BRACKET
30
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
30
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
40
CLAMP ,K 147121, Replaced By: N000000000319
40
CLAMP , Replaced By: N916016008200
40
CLAMP , Replaced By: A3604300143
50
SCREW CAP TO BRACKET
60
WASHER PLUG SOCKET TO BRACKET
70
NUT PUMP TO BRACKET
80
DISTRIBUTOR
80
DISTRIBUTOR EXHAUST BRAKE VALVE LINE CONNECTION
90
BRACKET DISTRIBUTOR
100
SCREW CLAMPING PIECE TO BRACKET M 6X40
110
NUT PUMP TO BRACKET
150
SCREW-IN FITTING LINE CONNECTION
160
SEAL RING COMPRESSED AIR LINE TO PARKING BRAKE VALVE
170
PLASTIC PIPE8X6 MM, ORDER BY THE METER
170
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
180
UNION NUT LINE CONNECTION
190
GLAND LINE CONNECTION
200
SLEEVE LINE CONNECTION
200
FITTING , Replaced By: N915062006000
210
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
212
LINE FROM COMPRESSED AIR HOSE TO FITTING
214
UNION NUT
216
GLAND , Replaced By: A0019901667
218
CONNECTION FITTING , Replaced By: A0039979172
240
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
250
SEAL RING COMPRESSED AIR LINE TO PARKING BRAKE VALVE
260
BRACKET , Replaced By: A3944297040
270
VALVE (THREE-WAY SOLENOID VALVE)
275
MAGNET24 V, TO 364 997 71 36
277
SCREW BRACKET MOUNTING
280
LOCK WASHER PLUG SOCKET
290
SCREW BEARING BRACKET TO SIDE MEMBER
300
NUT SUPPORT TO SIDE MEMBER
310
CONNECTOR SOLENOID VALVE,CONNECTION: "2"
320
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
330
SEAL RING COMPRESSED AIR LINE TO PARKING BRAKE VALVE
340
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
350
UNION NUT
360
GLAND , Replaced By: A0019901667
370
BUSHING , Replaced By: N915062004000
370
SLEEVE LEAK LINE
380
BRACKET AT CROSS MEMBER
390
SCREW , Replaced By: N304017010040
400
WASHER GROUND CABLE
410
NUT BRACKET TO SIDE MEMBER,XB209706
420
ELBOW FITTING AT CYLINDER
430
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
430
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
440
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
450
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
460
BRAKE HOSE , Replaced By: N071435006002
470
UNION NUT
480
GLAND , Replaced By: A0019901667
490
CONNECTION FITTING , Replaced By: A0039979172
505
CLAMP COMPRESSED AIR LINE TO COMPRESSED AIR LINE
505
CLAMP SENSOR CABLE TO FRONT AXLE
510
SCREW CABLE TO ALTERNATOR
520
WASHER PLUG SOCKET TO BRACKET
530
NUT PUMP TO BRACKET
540
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
550
GLAND , Replaced By: A0019901667
560
UNION NUT
570
BUSHING , Replaced By: N915062004000
570
SLEEVE LEAK LINE
600
CLAMP COMPRESSED AIR LINE TO COMPRESSED AIR LINE
600
CLAMP SENSOR CABLE TO FRONT AXLE
610
SCREW OVERLOAD PROTECTOR TO BRACKET
620
WASHER PLUG SOCKET TO BRACKET
630
NUT PUMP TO BRACKET
999
NUT
999
VALVE PART
999
PROTECTIVE CAP
999
SEAL RING
