Поз.
Артикул
Описание
8
FUEL TANK ,A 069749
8
FUEL TANK
16
FILLER CAP
16
FILLER CAP
24
DICHTUNG. SEAL RINGTO 312 470 12 05
24
SEAL RING
32
CHAIN FILLER CAP
40
SEAL RING CONNECTION: 1,4 719029
44
FITTING
48
RISING PIPE ,A 069205
56
FITTING
64
FUEL STRAINER
72
SEAL RING FUEL STRAINER SCREEN
80
GASKET FUEL GAUGE SENDER UNIT TO FUEL TANK
80
GASKET SENDER UNIT AND COVER TO FUEL TANK
88
SENDER UNIT , FROM CHASSIS A 002288
91
RELAY ,A 069749
96
NUT
104
GASKET FUEL GAUGE SENDER UNIT TO FUEL TANK
112
SUPPORT FUEL TANK
120
SUPPORT FRONT
120
SUPPORT REAR
128
SCREW BRACKET TO FRAME
136
LOCK WASHER SUPPORT TO SIDE MEMBER
138
RUBBER STRIP , Replaced By: A3459837391
144
BASE SUPPORT TO SIDE MEMBER
152
SCREW BRACKET TO SIDE MEMBER M 14X1.5X50,5 543914
160
WASHER TRAILER COUPLING TO REAR CROSS MEMBER
160
WASHER , Replaced By: A3379900440
168
NUT , Replaced By: N910113014000
176
STRAP FUEL TANK TO SUPPORT
184
NUT BRACKET TO LEFT SIDE MEMBER
184
HEX. NUT. NUT FUEL TANK TO CONSOLE,167609
192
WASHER
