Поз.
Артикул
Описание
147
AIR INTAKE PIPE FROM FILTER TO ENGINE,A 088317
154
HOSE FROM AIR CLEANER TO ENGINE INTAKE PIPE
154
HOSE AIR
157
AIR INTAKE PIPE TURBOCHARGER,A 088317
157
AIR INTAKE PIPE TURBOCHARGER,A 088318
158
HOSE , Replaced By: A0009970152
159
HOSE FROM AIR CLEANER TO OIL SEPARATOR,A 088318
160
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
160
LOOM TIE25-36 MM
160
LOOM TIE , Replaced By: N916017020000
160
CLAMP , Replaced By: N000000000667
161
CLAMP
162
SPACER TUBE BRACKET
163
RUBBER PAD
164
SCREW PLUG SOCKET TO FRAME
164
SCREW AIR SPRING VALVE TO BRACKET
165
WASHER , Replaced By: N000125008443
166
NUT , Replaced By: N913004008001
175
CLAMP100-120
175
LOOM TIE
175
CLAMP
189
CLAMP AS REQUIRED
189
CLAMP. LOOM TIE90-110
