Поз.
Артикул
Описание
21
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
30
VALVE"WABCO DO BRASIL"
30
VALVE"WESTINGHOUSE"
35
HANDLETO 000 434 24 01
40
PROTECTIVE CAPTO 000 434 08 01,345 434 71 01
40
CUP 3/2-WAY VALVE WABCO
45
SEAL RINGTO 000 434 23 01
50
CLEANERTO 000 434 22 01
55
REPAIR KIT ADDITIONAL CLUSTER GEAR VALVE TO 000 434 06 01
55
REPAIR KIT SMALL SCOPE TO 345 434 71 01
57
REPAIR KIT 3/2-WAY VALVE WABCO
60
ELBOW FITTING AT CYLINDER
60
ELBOW FITTING TEST CONNECTION TO BRACKET
65
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
65
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
70
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
75
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
80
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
85
SEAL RING LINE CONNECTION
90
GROMMET MAIN CABLE HARNESS THRU CAB
95
WASHER CLUTCH PEDAL AND BRAKE PEDAL
100
PROTECTIVE PLATE OPERATING VALVE TO SIDE MEMBER SHELL
105
NUT , Replaced By: N080705026003
110
SPRING WASHER OPERATING VALVE TO SIDE MEMBER SHELL
110
SPRING WASHER OPERATING VALVE TO SIDE MEMBER SHELL
999
REPAIR KIT , Replaced By: A0034301281
999
NUT ,D 091466
