Поз.
Артикул
Описание
893
PULL ROD , FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927
894
YOKE PULL ROD TO LEVER
896
YOKE , FROM IDENT NO. 674068 ALSO INSTALLED ON 5000001-599999,673432, 673497, 673628,673629,673921
897
NUT BATTERY CABLE
897
NUT BRACKET TO SUPPORT AND TO END PIECE
900
PIN PULL ROD TO BRAKE LEVER,REAR AXLE
900
PIN PISTON ROD TO LEVER, 415 5 014668 416 5 000515 417 4 972023
901
SPRING WASHER SHIFTING ROD TO BRACKET
901
SPRING WASHER , Replaced By: N000137010205
902
WASHER VIBRATION ABSORBER TO BRACKET
902
WASHER , Replaced By: N000433010510
904
BRAKE INTERMEDIATE SHAFT , FROM CHASSIS 734560 ALSO INSTALLED ON, 500001-599999
904
BRAKE INTERMEDIATE SHAFT , 670068-734559
904
BRAKE INTERMEDIATE SHAFT , FROM CHASSIS 734560 ALSO INSTALLED ON, 500001-599999
904
BRAKE INTERMEDIATE SHAFT , 674067
906
SEAL HOLDER
907
SEAL RING
908
BEARING BRACKET , FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927
909
SPHERICAL PIECE , Replaced By: A3025860242
910
EXPANSION PLUG
911
BALL CUP BRAKE INTERMEDIATE SHAFT BEARING
911
REPAIR KIT , Replaced By: A3534200167
911
REPAIR KIT , Replaced By: A3534200067
914
SPRING WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
915
WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
915
WASHER , Replaced By: N000433013010
917
BRACKET , UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
917
BRACKET , UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
920
BRAKE CAMSHAFT ,100570
920
BRAKE CAMSHAFT , UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
922
CUP
923
ADJUSTING LEVER LEFT
925
STUD
926
NUT , UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
927
SCREW
928
NUT CAB FLOOR
928
NUT , Replaced By: N308675012000
929
LEVER LEFT, UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
929
LEVER , Replaced By: A3604260611
929
LEVER , Replaced By: A3604260611
933
SCREW SHOCK ABSORBER TO UPPER BEARING BRACKET,5 261497
934
LOCK WASHERROCKINGER TYP 59 G140,59 G150
936
SPHERICAL PIECE , Replaced By: A3025860242
937
RADIAL SEAL RING
938
GREASE NIPPLE PROTECTIVE TUBE
939
EXPANSION PLUG BRAKE SHAFT TO BEARING BRACKET
940
LOCK STEERING KNUCKLE,TOP AND BOTTOM
940
LOCK RING
942
SPACER TUBE AS REQUIRED 10.5MM, UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
942
SPACER TUBE AS REQUIRED 13.5MM, UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
942
SPACER TUBE AS REQUIRED 13.0MM, FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927 UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501414,FROM CHASSIS 910370 AND 501415-599999 SEE SPARE PARTS LIST 744.3
942
SPACER TUBE AS REQUIRED 12.5MM, UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
942
SPACER TUBE AS REQUIRED 12.0MM, FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927 UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501414,FROM CHASSIS 910370 AND 501415-599999 SEE SPARE PARTS LIST 744.3
942
SPACER TUBE AS REQUIRED 11.5MM, FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927 UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501414,FROM CHASSIS 910370 AND 501415-599999 SEE SPARE PARTS LIST 744.3
942
SPACER TUBE AS REQUIRED 11.0MM, FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927 UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501414,FROM CHASSIS 910370 AND 501415-599999 SEE SPARE PARTS LIST 744.3
944
LOCK RING DRIVE GEAR
945
LOCK RING. RETAINING RING OIL PUMP TO TRANSMISSION CASE
947
REPAIR KIT BRAKE CAMSHAFT BEARING, FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927 UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501414,FROM CHASSIS 910370 AND 501415-599999 SEE SPARE PARTS LIST 744.3
947
REPAIR KIT , Replaced By: A3024200067
999
SCREW PLUG , Replaced By: A0004315433
999
PROTECTIVE CAP , Replaced By: A0004217187
999
PROTECTIVE CAP , Replaced By: A3454237020
999
PROTECTIVE CAP ,5 962906
999
SCREW FITTING (AT INTAKE). FITTING , TO TANDEM BRAKE MASTER CYLINDERS 001 430 51 01 AND 001 430 68 01
999
THRUST PINTEVES
999
THRUST PIN SEE FIG. NO.: 080,FB330168
999
CUP , UP TO IDENT NO 910369 EXCEPT FOR 501415-599999,FROM IDENT NO 910370 ALSO INSTALLED ON 501415-599999,SEE 744.4 UNIT SPARE PARTSLIST
999
PISTON , UP TO IDENT NO 910369 EXCEPT FOR 501415-599999,FROM IDENT NO 910370 ALSO INSTALLED ON 501415-599999,SEE 744.4 UNIT SPARE PARTSLIST
999
PROTECTIVE CAP , Replaced By: A3454237087
999
SPRING , UP TO IDENT NO 910369 EXCEPT FOR 501415-599999,FROM IDENT NO 910370 ALSO INSTALLED ON 501415-599999,SEE 744.4 UNIT SPARE PARTSLIST
999
BRACKET. LOCK , Replaced By: A6525040038
999
DIAPHRAGMTO 344 429 73 44
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
VALVE
999
ELBOW FITTING PRESSURE REGULATOR,CONNECTION "1"
999
VALVE
999
REPAIR KITTO 002 431 15 06,WABCO, 975 300 750 0,5 161700
999
REPAIR KIT DIAPHRAGM PART BOSCH,209
999
PISTON REPAIR KIT TO 002 430 88 01,002 430 82 01
999
REPAIR KIT SEAL RING BOSCH,209
999
VALVE , Replaced By: A3075530107
999
BANJO UNIONKUGELFISCHER
999
ANSCHLUSSSTUCK. THREADED UNION
999
SLIDETO 000 431 50 14,000 431 24 14
999
FILTER BOTTOMTO 000 431 24 14
999
GASKETTO 000 431 77 14,KNORR
999
SCREW PLUG , TO TANDEM BRAKE MASTER CYLINDERS 002 430 89 01
999
CUPTO 000 431 21 14,BOSCH, WITH BOSCH CHARACTERISTIC NUMBER 724
999
PROTECTIVE CAP VALVE, 674067
999
CUP , Replaced By: A0004319186
999
CUP , Replaced By: A0015864342
999
PISTONTO 000 431 21 14,BOSCH
999
PROTECTIVE CAPTO 000 431 24 14
999
PRESSURE REGULATORBOSCH,4 208907 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
SEAL RINGTO 002 430 69 01
999
CUP , WITH BOSCH CHARACTERISTIC NUMBER 723, Replaced By: A0004312786, +001A0004318583
999
SEAL RINGTO 002 430 72 01,SCHAEFER
999
SEAL RINGTO 002 430 69 01
999
CUPTO 000 431 76 14
999
CUPTO 000 431 77 14,KNORR
999
VALVE , Replaced By: A0004320807
999
REPAIR KIT WHEEL CYLINDER
999
REPAIR KIT , Replaced By: A0004303083
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
RUBBER STRIP
999
PLASTIC PIPE RISING PIPE 4X6 MM
999
HOLLOW SCREWKUGELFISCHER
999
SPRINGTO 002 430 69 01
999
THRUST RING CHECK VALVE TO AIR RESERVOIR
999
SCREW. UNION SCREW LINE CONNECTION
999
VALVE (OVERFLOW VALVE) BOSCH
999
VALVE (OVERFLOW VALVE) GRAU
999
REPAIR KIT PRESSURE REGULATOR WABCO
999
CUP , Replaced By: A0004312786
999
SEAL RINGTO 000 431 77 14,KNORR,4 415092
999
REPAIR KITTO 001 429 52 44
999
SCREW ,374026
999
SCREW CLAMP MOUNTING
999
SCREW BRAKE LINE MOUNTING
999
SCREW PROTECTION PLATE TO BRACKET
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
COTTER PIN LEVER TO ROD
999
COTTER PIN
999
COTTER PIN VIBRATION ABSORBER TO BRACKET,5 117575
999
COTTER PIN CYLINDER TO BRACKET
999
COTTER PIN STRAP TO CONSOLE
999
COTTER PINROCKINGER TYP 260 G140
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125010532
999
WASHER RADIATOR TO RUBBER MOUNTING
999
LOCK RING
999
LOCK RING
999
SCREW CLUTCH TO FLYWHEEL
999
SCREW BRACKET TO FRAME SIDE MEMBER
999
SCREW BRACKET TO BELL HOUSING
999
SCREW , Replaced By: N304017008021
999
SCREW BRACKET TO BATTERY/APPARATUS SUPPORT
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SCREW , Replaced By: N304017010002
999
SCREW REAR EXHAUST PIPE TO MUFFLER
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW , Replaced By: N304017010028
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
NUT BALL PIVOT TO LEVER
999
SCREW CLAMP MOUNTING M 6X16
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
SHEET METAL SCREW FUEL STRAINER SCREEN TO FUEL TANK
999
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
999
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
999
WASHER BUMPER BRACKET TO COUPLING MOUTH
999
WASHER BRACKET TO SIDE MEMBER
999
GROMMET LINE MOUNTING 19/13 MM
999
BRACKET , Replaced By: A3812711640
999
GROMMET TEMPERATURE GAUGE SENDER UNIT
999
BRACKET DELIVERY AND SUCTION LINES
999
CLAMP FEED LINE TO THERMOSTAT
999
CLAMP LINE MOUNTING
999
WASHER WATER SEPARATOR
999
WASHER BRACKET TO SIDE MEMBER
999
WASHER , Replaced By: A4219905440
999
BRACKET LINE MOUNTING
999
CONSOLE
999
CONSOLE , Replaced By: A3164300111
999
CLAMP , Replaced By: N916016008200
999
LEVER RIGHT,2 068748
999
LEVER , Replaced By: A3604260711
999
BRAKE SHOE ,910369 EXCEPT FOR 501456-599999910370 ALSO INSTALLED ON 501456-599999, SEE SPARE PARTS LIST 731.3, Replaced By: A3024202019, +002A3604210810, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024202019, +002A3604212510, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024202019, +002A3604212410, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024202119, +002A3604231510, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024202119, +002A3604231410, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024202119, +002A3604231310, +016A3079900197
999
BRAKE SHOE , FROM REAR AXLE 029312-035499, FROM REAR AXLE K 000001-K 038371, Replaced By: A3024202119, +001A3024210088, +002A3604232810, +016A3079900197
999
BRAKE SHOE , FROM REAR AXLE 029312-035499, FROM REAR AXLE K 000001-K 038371, Replaced By: A3024202119, +001A3024210088, +002A3604230110, +016A3079900197
999
BRAKE SHOE ,100570, Replaced By: A3604209120, +001A3024210088
999
LEVER AT BRACKET, 674067
999
BEARING BRACKET
999
BRAKE LEVER
999
RUBBER STRIP , Replaced By: A0009870814
999
REPAIR KIT , Replaced By: A3584200182
999
BRAKE LEVER , 715475
999
BEARING BRACKET BRAKE CABLE, 674067
999
RATCHET ROD
999
REPAIR KIT BRAKE SHOE MOUNTING BOLT
999
BRAKE ANCHOR PLATE , 737611-796990
999
BRAKE SHOE , Replaced By: A3024200019, +002A3604232810, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024200019, +002A3604230110, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024200019, +002A3604230010, +016A3079900197
999
BUSHING
999
PIN PULL ROD TO BRAKE INTERMEDIATE LEVER
999
BRACKET , Replaced By: A3274925819
999
BRACKET BRAKE MASTER CYLINDER
999
PIN , UP TO CHASSIS 698032 EXCEPT 500001-599999
999
RESERVOIR FRONT AXLE, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS A 059728 EXCEPT FOR: A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059525,A 059526,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
999
LEVER
999
LEVER , Replaced By: A3524301423
