Поз.
Артикул
Описание
750
STEERING WHEEL ,5 057904 NO.8316INO.7C52INO.7B90INO.9051I II I
750
STEERING WHEEL
750
STEERING WHEEL ,4 767536, Replaced By: A0004641101, +001A0004642631
753
CAPTO 000 464 11 01
756
PROTECTIVE RING
770
BEARING PLEASE REFER TO ADDITIONAL PARTS
770
BEARING , Replaced By: A3354600537, +001A3524623901, +002A0119815110
770
BEARING PLEASE REFER TO ADDITIONAL PARTS
770
BEARING , Replaced By: A3354600537, +001A3524623901, +002A0119815110
770
BEARING , Replaced By: A3354600337
774
NEEDLE BEARING
774
BUSHING ,582084
778
RING
782
COVER
790
BOOT STEERING COLUMN TO CAB
790
BOOT , Replaced By: A3604620596
795
UNIVERSAL JOINT , UP TO IDENT NO. 709912 EXCEPT FOR 500001-599999
795
UNIVERSAL JOINT , Replaced By: A3164600157
798
UNIVERSAL JOINT CROSS , UP TO IDENT NO. 622785 EXCEPT FOR 500001-599999
802
SEAL HOLDER , UP TO IDENT NO. 622785 EXCEPT FOR 500001-599999
806
RUBBER RING , UP TO IDENT NO. 622785 EXCEPT FOR 500001-599999
810
BEARING BUSHING O.D., 28.024 BIS 28.036 MM
810
BEARING BUSHING , 005,006,007,011,012,021,031,106,108 UP TO CHASSIS A 011990
814
NEEDLE SET192 PIECES, UP TO IDENT NO. 622785 EXCEPT FOR 500001-599999
814
NEEDLE , 005,006,007,011,012,021,031,106,108 UP TO CHASSIS A 011990
818
SNAP RING1.70 MM, 032,033,040,041: UP TO CHASSIS 039639 132,133,140,141: UP TO CHASSIS 000510
818
SNAP RING1.65 MM, 032,033,040,041: UP TO CHASSIS 039639 132,133,140,141: UP TO CHASSIS 000510
818
SNAP RING1.60 MM, 032,033,040,041: UP TO CHASSIS 039639 132,133,140,141: UP TO CHASSIS 000510
818
SNAP RING1.55 MM, 032,033,040,041: UP TO CHASSIS 039639 132,133,140,141: UP TO CHASSIS 000510
818
SNAP RING1.50 MM, 032,033,040,041: UP TO CHASSIS 039639 132,133,140,141: UP TO CHASSIS 000510
818
SNAP RING1.75 MM, 032,033,040,041: UP TO CHASSIS 039639 132,133,140,141: UP TO CHASSIS 000510
824
UNIVERSAL JOINT , Replaced By: A3444607057
824
UNIVERSAL JOINT ,5 463985
824
UNIVERSAL JOINT , Replaced By: A0004600157, +002A3819900114
824
UNIVERSAL JOINT ,5 463985
824
UNIVERSAL JOINT ,5 463985, Replaced By: A0004600057, +002A3819900114
824
UNIVERSAL JOINT , UP TO IDENT NO. 709912 EXCEPT FOR 500001-599999
828
STEERING SHAFT BOTTOM, 712854
828
STEERING SHAFT BOTTOM, 712854
828
STEERING SHAFT BOTTOM, 10/50 FROM CAHSSIS 629395-712853, 20/60 FROM CAHSSIS 601109-712853
832
STEERING SHAFT TOP,5 210004
832
STEERING SHAFT ,5 0579045 210003, Replaced By: A3524623601, +001A3434600237, +002A0119815110
832
STEERING SHAFT PLEASE REFER TO ADDITIONAL PARTS,5 057903
832
STEERING SHAFT ,5 057903, Replaced By: A3524624101, +001A3434600237, +002A0119815110
832
STEERING SHAFT TOP,5 210004
832
STEERING SHAFT ,5 0579045 210003, Replaced By: A3524623101, +001A3434600237, +002A0119815110
832
STEERING SHAFT PLEASE REFER TO ADDITIONAL PARTS,5 057903
832
STEERING SHAFT TOP, 032,033,040,041: FROM CHASSIS 039640 132,133,140,141: FROM CHASSIS 1600092582084
834
SCREW STEERING SHAFT TO STEERING M 8X42
834
SCREW UNIVERSAL JOINT TO STEERING COLUMN M 8X38,5 463984
834
SCREW , Replaced By: A3169900114
840
NUT STRAP TO BRACKET
843
WOODRUFF KEY FLANGE TO SHIFTING TUBE
846
NUT STEERING WHEEL TO STEERING COLUMN,4 628576
850
SEAL RING STEERING COLUMN TUBE THRU CAB FLOOR,D 591979
854
BOOT STEERING COLUMN TUBE THRU CAB FLOOR,D 591979
857
BOOT STEERING COLUMN TUBE THRU CAB FLOOR
999
FILTER ELEMENT ,D 441028D 523393
999
OIL LINE FROM PUMP TO STEERING
999
OIL PIPE. LINE RETURN LINE TO TRANSMISSION
999
BOOT FIXED PART OF JOINT
999
BOOT FIXED PART OF JOINT
999
JOINT R.H. THREAD LEMFOERDER
999
CLAMP CLAMP, TWO-HOLE
999
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
999
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
999
STEERING NUT
999
STEERING NUT , UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
999
NUT , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SCREW , Replaced By: A0004621871, +001A0004620372
999
LOCK , Replaced By: A0005861846
999
PISTON
999
BALL RACE , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
RING
999
CONNECTOR ,12068000, 344.030,031,032,03312009117, 345.001,002,003,300
999
TANK
999
CLAMP , Replaced By: N916016010203
999
CLAMP , Replaced By: N916016022202
999
FITTING ,12068000, 344.030,031,032,03312009117, 345.001,002,003,300
999
JOINT R.H. THREAD LEMFOERDER,5 180856
999
JOINT R.H. THREAD EHRENREICH,5 180856
999
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
999
NEEDLE BEARING STEERING SHAFT BEARING, FROM STEERING 000384
999
NEEDLE BEARING STEERING SHAFT BEARING,000384
999
NEEDLE BEARING
999
SEAL RING AT VICKERS PUMP, 10 UP TO CHASSIS 629394,20 UP TO CHASSIS 601108
999
STEERING BRACKET , 10 UP TO CHASSIS 629394,20 UP TO CHASSIS 601108
999
LINE
999
STEERING BRACKET , 902202, Replaced By: A3524601829, +004A3529903701, +002A3559900501, +006N913004014005
999
STEERING BRACKET , 902202, Replaced By: A3524601929, +004A3529903701, +002A3559900501, +006N913004014005
999
STEERING BRACKET , 902203
999
LINE FROM OIL TANK TO HOSE
999
STEERING BRACKET , 902203
999
STEERING SHAFT BOTTOM, 10 UP TO CHASSIS 629394,20 UP TO CHASSIS 601108
999
STEERING INTERMEDIATE ARM , USED WITH HYDRAULIC BRAKE
999
LINE FROM TANK TO HOSE
999
LINE FROM STEERING TO OIL TANK
999
LINE FROM OIL TANK TO HOSE, 10 UP TO CHASSIS 629394,20 UP TO CHASSIS 601108
999
SCREW STEERING BRACKET TO FRAME
999
CLAMPING PIECE DELIVERY AND SUCTION LINES TO BEARING BRACKET
999
BRACKET DELIVERY AND SUCTION LINES
999
SCREWM 14X14X24X42
999
PISTON STROKE LIMIT
999
STEERING BOX , 030298, Replaced By: A3604603002, +001A3604602214
999
STEERING BOX ,031316, Replaced By: A3604603102, +001A3604602314
999
STEERING BOX WITH SLEEVE VALVE
999
LINE FROM HOSE TO PUMP
999
LINE FROM STEERING TO OIL TANK,4 428827
999
SCREW
999
BEARING RING
999
BEARING RING
999
THRUST WASHER STEERING SHAFT BEARING,000383
999
BEARING RING
999
SCREW , PART NO LONGER AVAILABLE,ORDER RANGE OF DELIVERY
999
WASHER , PART NO LONGER AVAILABLE,ORDER RANGE OF DELIVERY
999
PISTON
999
LINE , Replaced By: A3604603624
999
LINE FROM OIL TANK TO PUMP, 10 UP TO CHASSIS 629394,20 UP TO CHASSIS 601108
999
SPRING , PART NO LONGER AVAILABLE,ORDER RANGE OF DELIVERY
999
SPRING , PART NO LONGER AVAILABLE,ORDER RANGE OF DELIVERY
999
CLAMP LINE MOUNTING
999
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
BRACKET LINE TO CAB CONSOLE
999
DISC SPRING
999
DISC SPRING
999
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
999
COTTER PINROCKINGER TYP 260 G140
999
COTTER PIN , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
COTTER PINROCKINGER,TYP 260 G150,260 G140
999
WASHER , Replaced By: N000125010532
999
WASHER RADIATOR TO RUBBER MOUNTING
999
SPRING WASHER STEERING COLUMN BRACKET TO CAB
999
WIRE STEERING BOX ASSEMBLY TO STEERING SUPPORT 600 MM
999
LOCK PLATE , Replaced By: A0005861846
999
LOCK PLATE P.T.O. TO TRANSMISSION
999
SCREW BRACKET TO FRAME SIDE MEMBER
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N304017006018
999
SCREW , Replaced By: N304017006020
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017008027
999
SCREW , Replaced By: N304017008034
999
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SCREW REAR EXHAUST PIPE TO MUFFLER
999
NUT BALL PIVOT TO LEVER
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
NUT , Replaced By: N308673012002
999
NUT SHOCK ABSORBER TO CONSOLE AND TO CAB, UP TO CHASSIS 781743 EXCEPT FOR 500001-599999
999
NUT INTERMEDIATE LEVER TO FRAME
999
SCREW INTERMEDIATE LEVER TO FRAME M 12X1.5X40
999
SCREW CLAMP, TWO-HOLE
999
SCREW , Replaced By: N308676012017
999
SCREW-IN FITTING SUCTION LINE TO OIL PUMP
999
BALL10 MM
999
SEAL RING FUEL LINE TO FEED PUMP
999
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
SCREW LICENSE PLATE TO BRACKET
999
SCREW PIPE CLAMP
999
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
NUT
999
NUT BATTERY CABLE
999
NUT. HEXAGON NUT SHOCK ABSORBER MOUNTING
999
HEXAGON HEAD BOLT. SCREW BRACKET TO CROSS MEMBER
999
HEXAGON HEAD BOLT. SCREW CLAMP TO DRAG LINK
999
CLAMP STEERING SHAFT THRU CAB
999
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
999
NUT STEERING SUPPORT TO FRAME
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
LOCK WASHER FITTING TO BRACKET
999
NUT , Replaced By: N910113012003
999
NUT , Replaced By: N910113014000
999
CLAMP HEATER-PLUG/SOLENOID-VALVE BRANCH-OFFS TO NOZZLE HOLDER,K 092646
999
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
999
CLAMP , Replaced By: N000000000667
