Поз.
Артикул
Описание
5
VALVE (3/2-WAY SOLENOID VALVE) EKS
5
VALVE CONSTANT THROTTLE
5
VALVE , Replaced By: A0049975736
10
PROTECTIVE CAPWABCO
14
SEAL RINGWABCO
18
VALVE (3/2-WAY SOLENOID VALVE)
20
REPAIR KIT 3/2-WAY SOLENOID VALVE
21
BRACKET 3/2-WAY SOLENOID VALVE
22
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
22
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
23
SCREW SWITCH TO BRACKET
24
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
24
SCREW , Replaced By: N304017008016
25
WASHER , Replaced By: N009021005205
25
WASHER , Replaced By: N009021008213
25
WASHER BRACKET TO LEFT SIDE MEMBER
25
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
25
WASHER BRACKET TO CAB REAR PANEL
26
NUT , Replaced By: N913004008001
26
NUT TWO-WAY VALVE TO BRACKET
30
FITTING PARKING BRAKE VALVE,CONNECTION: "23"
33
FITTING LINE CONNECTION
33
FITTING PARKING BRAKE VALVE
34
THRUST RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
36
SEAL RING 3/2-WAY VALVE
36
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
38
SEAL RING LINE CONNECTION
40
SEAL RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
42
SCREW. UNION SCREW LINE CONNECTION
42
SCREW. UNION SCREW , Replaced By: A0009973734
44
SEALING RING. SEAL RING ENGINE BREATHING
45
HOLLOW SCREW LINE CONNECTION
48
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
48
SEAL RING LINE CONNECTION
