Поз.
Артикул
Описание
5
CAMSHAFT
10
THRUST WASHER
15
SPACER WASHER
20
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
25
SCREW COVER PLATE TO COVER PLATE
30
DRIVE GEAR , 006862
35
WOODRUFF KEY CRANKSHAFT
40
CAMSHAFT GEAR
45
SCREW BRACKET TO CONSOLE
45
SCREW , Replaced By: N304017010043
50
VALVE TAPPET
55
PUSH ROD
60
ROCKER ARM , Replaced By: A3270500633
60
ROCKER ARM
65
BUSHING
70
SPRING
75
SET SCREW ROCKER ARM
80
NUT
85
ROCKER ARM SPINDLE
90
EXPANSION PLUG BELL HOUSING
95
ROCKER ARM BRACKETNO.1,3,4,6
100
ROCKER ARM BRACKETNOS. 2,NOS 5
105
SCREW ROCKER SHAFT TO CYLINDER HEAD
110
SCREW
115
LOCK WASHER BATTERY BASE FRAME TO BATTERY/APPARATUS SUPPORT
120
SPRING SHORT,ROCKER ARM SPACING
125
SPRING
130
EXHAUST VALVE
130
INTAKE VALVE
130
INTAKE VALVE , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 103937, Replaced By: A3600530001
130
EXHAUST VALVE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3600500227
140
VALVE SPRING
145
SPACER RING
150
SPRING RETAINER
155
VALVE COLLET
999
CAMSHAFT GEAR ,000759, Replaced By: A3600520001, +001A3600770014
999
SPACER RING , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 069835, Replaced By: A3600530051
999
DRIVE GEAR ,006861, Replaced By: A3600770014, +001A3600520001
