Поз.
Артикул
Описание
15
AXLE HOUSING REAR AXLE II
15
AXLE HOUSING REAR AXLE I
20
CYLINDRICAL PIN RIGHT FRONT
25
SCREW THRUST ARM TO SPRING BRACKET
27
PIN REAR AXLE HOUSING
29
PLUG AXLE HOUSING
31
BEARING BRACKET
33
THRUST RING
33
THRUST RING
37
OIL COLLECTOR ,100570
39
BUSHING
41
SEAL RING , Replaced By: A0219972947
41
SEAL RING ,825817, 301,303,304,305, 868276, 311,313,314825818, 301,303,304,305, 868277, 311,313,314 SEE SPARE PARTS LIST 740.3
43
COVER
45
GREASE NIPPLE , Replaced By: N071412008102
45
GREASE NIPPLE
60
FLANGE REAR AXLE HOUSING
62
GASKET AXLE HOUSING
64
SCREW BRACKET TO SIDE MEMBER
70
BEARING BUSHING SHIFTING FORK TO REAR AXLE HOUSING
75
VALVE
75
FITTING BLEEDING
80
SCREW PLUG TOP AND BOTTOM
155
CYLINDR. ROLLER BEARING PINION,INSIDE
155
CYLINDR. ROLLER BEARING PINION,INSIDE
155
CYLINDR. ROLLER BEARING PINION,INSIDE
160
SNAP RING DRIVE PINION
165
SNAP RING REAR AXLE HOUSING
170
SPACER WASHER AS REQUIRED 0.50 MM
170
SPACER WASHER AS REQUIRED 0.20 MM
170
SPACER WASHER DRIVE PINION 0.10 MM
180
TAPERED ROLLER BEARING DRIVE PINION,ON PINION END
185
SPACER RING DRIVE PINION
190
SPACER WASHER7.40 MM, 021605
190
SPACER WASHER7.34 MM
190
SPACER WASHER AS REQUIRED 7.32 MM, FROM REAR AXLE 021605
190
SPACER WASHER AS REQUIRED 7.28 MM, FROM REAR AXLE 021605
190
SPACER WASHER7.22 MM
190
SPACER WASHER DRIVE PINION 7.16 MM, FROM REAR AXLE 021605
190
SPACER WASHER AS REQUIRED 7.10 MM, FROM REAR AXLE 021605
190
SPACER WASHER7.04 MM, 021605
190
SPACER WASHER6.98 MM
190
SPACER WASHER6.96 MM, 021605
190
SPACER WASHER AS REQUIRED 6.94 MM, FROM REAR AXLE 021605
190
SPACER WASHER6.92 MM, 021605
190
SPACER WASHER AS REQUIRED 6.88 MM, FROM REAR AXLE 021605
190
SPACER WASHER AS REQUIRED 6.86 MM, FROM REAR AXLE 021605
190
SPACER WASHER DRIVE PINION 6.80 MM, FROM REAR AXLE 021605
200
TAPERED ROLLER BEARING DRIVE PINION,ON FLANGE END, FROM REAR AXLE 021605
200
TAPERED ROLLER BEARING OUTSIDE, FROM REAR AXLE 021605
200
TAPERED ROLLER BEARING , UP TO REAR AXLE 021604
205
THRUST WASHER
210
SCREW COLLAR DRIVE PINION TO RAER AXLE HOUSING
220
SEAL RING
225
LOCK AXLE HOUSING
230
TOOTHED WASHER
232
SCREW , Replaced By: N304017008039
232
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
240
FLANGE ,464537, 376.041,042,043,044
242
NUT COUPLING FLANGE TO DRIVE SHAFT,5 298189
260
SET SCREW AXLE HOUSING
262
SLIDE AXLE HOUSING
264
NUT AXLE HOUSING
270
SCREW (PRESSURE SCREW),BEARING COVER
272
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
280
COVER REAR AXLE I
280
COVER AXLE HOUSING
285
SCREW PLUG BELL HOUSING
287
GASKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3613510180
287
GASKET REAR AXLE I
287
GASKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3833510580
287
GASKET COVER TO DIFFERENTIAL CASE
290
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
292
SCREW , Replaced By: N304017010028
292
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
295
SCREW PLUG , Replaced By: A0009972632
300
SHAFT
305
ANGULAR CONTACT BEARING MAIN SHAFT,REAR, UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
305
ANGULAR CONTACT BEARING ,4 473926 FROM IDENT NO. SEE MICROFICHE MODEL 714.0 FROM IDENT NO. SEE MICROFICHE MODEL 714.0
305
ANGULAR CONTACT BEARING , Replaced By: A3459817127
310
SEAL RING REAR AXLE I
315
FLANGE , 000200
325
SPACER WASHER0.10 MM
325
SPACER WASHER0.2 MM, 000200
325
SPACER WASHER AS REQUIRED 0.25 MM,1701058 SIMPLE PART-PLEASE HAVE SHOP MADE
325
SPACER WASHER0.50 MM
330
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
332
SCREW , Replaced By: A0029909704
335
SEAL RING POWER STEERING PUMP
340
FLANGE
345
NUT COUPLING FLANGE TO DRIVE SHAFT,5 298189
350
CYLINDR. ROLLER BEARING85 MM,4 473926 FROM IDENT NO. SEE MICROFICHE MODEL 714.0 FROM IDENT NO. SEE MICROFICHE MODEL 714.0
355
SPACER RING
360
SEAL RING REAR AXLE I
365
RETAINING RING. LOCK RING DRIVE SHAFT
370
SPACER RING
380
FLANGE
999
REPAIR KIT
999
REPAIR KIT , Replaced By: A3853500268
999
REPAIR KIT DIFFERENTIAL SPIDER,PIVOT: 30 MM
999
REPAIR KIT DIFFERENTIAL SPIDER,PIVOT: 29 MM
