Поз.
Артикул
Описание
5
ENGINE SUPPORT ON CLUTCH END
8
SHIM AS REQUIRED 1 MM
8
SHIM AS REQUIRED 2.5 MM
11
SCREW APPARATUS SUPPORT TO FRAME M 14X1.5X85
14
NUT , Replaced By: N910113014000
23
SHIM AS REQUIRED 3 MM
23
SHIM AS REQUIRED 2 MM
29
PLATE ENGINE SUPPORT TO SUBSTRUCTURE
32
WASHER
35
SCREW ENGINE TO ENGINE REAR MOUNTING M 14X1.5X90
47
RUBBER MOUNTING CLUTCH END
47
RUBBER MOUNTING REAR
47
RUBBER MOUNTING CLUTCH END
47
RUBBER MOUNTING
47
RUBBER MOUNTING CLUTCH END
47
RUBBER MOUNTING REAR
50
SCREENING PLATE REAR RUBBER MOUNTING
50
SCREENING PLATE ENGINE MOUNTING AND BRACKET TO SUPPORTING ARM
56
SCREW CONSOLE TO BRACKET M 12X1.5X25,20 L
62
NUT SUPPORT TO SIDE MEMBER
65
SUPPORTING ARM LEFT
65
SUPPORTING ARM RIGHT
68
BRACKET ENGINE ALONGSIDE FIXING
71
SCREW , Replaced By: N308676014012
71
SCREW MOUNTING TO CONSOLE M 14X55
77
WASHER IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.: 360 990 18 40
83
SCREW ENGINE REAR SUPPORT TO RUBBER MOUNTING M 16X45
86
WASHER , Replaced By: N000125017016
89
ROD ENGINE ALONGSIDE FIXING
92
ROD END LEFT TO 364 240 76 25
92
ROD END RIGHT TO 364 240 76 25
95
CLAMPTO 364 240 76 25
98
SCREW CLAMP TO DRAG LINK TO 344 338 73 45
101
LOCK WASHER , Replaced By: N912004010102
104
HEX. NUT. NUT SHIFT LEVER KNOB
107
BRACKET ENGINE ALONGSIDE FIXING
110
SHIM
113
STUD PULL ROD TO BEARING BRACKET
116
NUT FRONT SPRING TO FRONT SPRING FRONT AND REAR BRACKETS
119
SCREW BATTERY CASE TO SIDE MEMBER
122
NUT BRACKET TO SIDE MEMBER
