Поз.
Артикул
Описание
5
CLUTCH PRESSURE PLATE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
8
SPINDLE FOR BEDDING THE LEVERS IN CLUTCH PRESSURE PLATE
9
LOCK PLATE CLUTCH PEDAL RESET
11
ROLLER FOR BEDDING THE LEVERS IN BRACKETS
14
SLEEVE CLUTCH PRESSURE PLATE
17
SCREW RELEASE LEVER,BRACKET
20
PRESSURE SPRING SPRING STEEL WIRE DIA., 4.00 MM
20
PRESSURE SPRING SPRING STEEL WIRE DIA., 3.75 MM
23
SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
26
FLANGE
32
CLUTCH DISC ,C 070254
32
CLUTCH DISC , Replaced By: A0052506403
32
CLUTCH DISC ,C 070254
35
SCREW CLUTCH TO FLYWHEEL
38
LOCK WASHER , Replaced By: N912004010102
41
RELEASE BEARING
44
SCREW-IN FITTING RELEASE COLLAR LUBRICATION
47
HOSE RELEASE BEARING LUBRICATION
47
HOSE RELEASE BEARING LUBRICATION
50
UNION SCREW RELEASE COLLAR LUBRICATION
53
DOUBLE TAPER RING RELEASE COLLAR LUBRICATION
56
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
59
NUT BRACKET TO SIDE MEMBER
62
SCREW-IN FITTING RELEASE COLLAR LUBRICATION
65
GREASE NIPPLE RELEASE COLLAR LUBRICATION
68
CAP RELEASE BEARING LUBRICATION
999
PRESSURE PLATE
999
BRACKET RELEASE LEVER
999
LOCK FOR BRACKETS
999
NUT FOR BRACKETS
999
LEAF SPRING
999
RIVET LINING WITH CLUTCH DISC,5 563495
999
RIVET LEAF SPRING TO CLUTCH DISC
999
RIVET LINING WITH INTERMEDIATE SPRING,5 563495
999
RELEASE LEVER CLUTCH ACTUATION
999
HOUSINGTO 001 250 07 04,003 250 20 04
999
CLUTCH LINING
