Поз.
Артикул
Описание
115
EXHAUST PIPE FRT FRONT EXHAUST PIPE
117
CLAMP FRONT EXHAUST PIPE ON INTERMEDIATE PIPE 77 MM
117
CLAMP FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
121
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M8X35
121
SCREWM8X120,D 250888 NOT USED
127
NUT HORN TO BRACKET M8
133
BRACKET
141
PIPE-HOSE CONNECTOR
145
EXHAUST PIPE
149
PIPE CLAMP F EXHAUST SYS.
153
PIPE CLAMP F EXHAUST SYS.
157
SCREW , Replaced By: N910143008002
161
EXHAUST PIPE
163
CLAMP
167
BRACKET
171
SCREW BRACKET TO SIDE MEMBER M10X35
175
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
177
CLAMP FRONT EXHAUST PIPE TO MUFFLER
177
FASTENING CLAMP
183
PARTICULATE CONVERTER PARTICULATE REDUCTION CATALYTIC CONVERTER SYSTEM
189
BRACKET
193
BRACKET
193
BRACKET
195
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
197
BUFFER
203
NUT , Replaced By: N913023010002
207
RUBBER BUFFER EXHAUST MUFFLER
211
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
217
BRACKET
220
CLAMP FRONT EXHAUST PIPE TO MUFFLER
223
NOX SENSOR NOX PROBE
226
ELECTRIC CABLE ADAPTER "NOX"
230
SENDER UNIT TEMPERATURE SENSOR,EXHAUST T2
233
NUT. CLAMPING RING
