Поз.
Артикул
Описание
5
SHIFT LEVER
8
BUSHING PAWL TO ROD END,5 443047
11
BOOT SHIFTING ROD
14
VALVE GEARSHIFT LEVER LOWER PART WABCO
14
VALVE SHIFT LEVER HERION
17
HANDLE (SHIFT LEVER HANDLE)
23
NUT SHIFT LEVER HANDLE TO SHIFT LEVER
26
COVER SHIFT LEVER KNOB LESS GEARSHIFT DIAGRAM
29
GUMMED LABEL GEAR INDICATOR
32
JOINT BEARING SHIFT LEVER BEARING,K040603
32
JOINT BEARING SHIFT LEVER BEARING,K040603
35
LOCK RING SHIFT LEVER BEARING
38
PIN SHIFT LEVER BEARING,K040603
47
BOOT SHIFT LEVER BEARING
50
BRACKET SHIFT LEVER UPPER PART,K040603
53
BRACKET SHIFT LEVER LOWER PART,K040603
56
NUT BRACKET TO BRACKET
59
BUSHING SHIFT LEVER BEARING TO CAB FLOOR
62
RUBBER PAD SHIFT LEVER TO CAB FLOOR,K040603
65
TUBE. BUSHING CAB FLOOR COVERING
68
RUBBER PAD SHIFT LEVER BEARING TO CAB FLOOR
71
BRACKET SHIFT LEVER BEARING TO CAB FLOOR
74
BRACKET BOOT
77
SCREW BRACKET TO FRAME M 8X35
80
SHIFTING ROD REAR,4 8557044 921176
86
SHIFTING ROD (TELESCOPIC SHIFTING ROD)
89
ROD END HYDRAULIC RELEASE
92
CONNECTOR REAR SHIFTING ROD TO CONNECTOR
95
SEAL RING HYDRAULIC RELEASE
98
PAWL SHIFTING ROD,5 443048
101
BUSHING PAWL TO ROD END,5 443048
101
BUSHING PAWL TO ROD END,5 443048
104
SPACER TUBE SHIFTING ROD TO SHIFT LEVER
107
ROUND CORD RING. SEAL RING ROD END
110
SPRING ROD END
113
SPRING ROD END
116
SCREW BRACKET TO BEARING BRACKET,K 274033
119
NUT EXHAUST PIPE TO SIDE MEMBER
122
EXPANSION PLUG ROD END
125
SHIFTING CYLINDER HYDRAULIC RELEASE TECHNOMATIK
125
SHIFTING CYLINDER HYDRAULIC RELEASE WABCO
128
SEAL RING PISTON RINGS WABCO
131
SEAL RING SCREW FITTING WABCO
134
SEAL RING OUTSIDE WABCO
137
SPRING WASHER SHIFTING CYLINDER TO YOKE
140
PIN SHIFTING CYLINDER TO YOKE 8X45 MM
143
PIN SHIFTING CYLINDER TO PAWL 8X20 MM
146
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
149
WASHER BETWEEN THE SHIFTING RODS
152
SCREW FRONT SHIFTING ROD TO REAR SHIFTING ROD
155
NUT EXHAUST PIPE TO SIDE MEMBER
164
SPACER TUBE SHIFTING ROD TO SHIFT LEVER
167
ROUND CORD RING. SEAL RING ROD END
170
SCREW BRACKET TO BEARING BRACKET,K 274033
173
SPRING WASHER SHIFTING ROD TO SHIFT LEVER
176
NUT EXHAUST PIPE TO SIDE MEMBER
179
CONNECTOR , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A6172680028
999
WASHER , Replaced By: N000125010532
999
WASHER RADIATOR TO RUBBER MOUNTING
