Поз.
Артикул
Описание
41
FENDER ,5 005872
44
BRACKET FENDER TO BRACKET
47
CLAMPING PIECE
50
RIVET
53
SCREW
56
NUT
59
REINFORCEMENT FENDER FIXTURE 505 MM
59
REINFORCEMENT FENDER
62
SCREW REINFORCEMENT WITH FENDER BRACKET TO FENDER
62
SCREW BRACKET TO REAR FENDER
65
NUT BALL SOCKET TO ROD
68
SCREW , Replaced By: N000000001146
71
WASHER , Replaced By: N009021006208
74
NUT AT FILTER BRACKET
77
BEARING BRACKET , 393.311 UP TO CHASSIS 4 450302,393.321 UP TO CHASSIS 4 453 074,395.312,322,412,422 UP TO CHASSIS 4 426005
80
SCREW , Replaced By: N000000001441
83
NUT EXHAUST PIPE TO SIDE MEMBER
86
BRACKET TAIL LAMP
89
SCREW , Replaced By: N000000001441
92
NUT EXHAUST PIPE TO SIDE MEMBER
95
SCREW , Replaced By: N910105008043
98
NUT BRACKET TO BRACKET
101
EXPANSION PLUG BRACKET
104
STAY AT BEARING BRACKET
107
BRACKET , Replaced By: A6525222240
110
CLAMPING SLEEVE STAY TO FENDER BRACKET 8X45 MM
113
ANTINOISE CAPSULE REAR WHEELS
116
BRACKET COVERING TO FRONT FENDER
119
PIN COVERING AND PIN TO FENDER HALF SHELL
122
SCREW , Replaced By: A0029903712
125
WASHER , Replaced By: N009021006208
128
NUT AT FILTER BRACKET
