Поз.
Артикул
Описание
17
VALVE 4/2-WAY
20
REPAIR KIT 4/2-WAY VALVE TO 000 260 14 57
23
BRACKET 4/2-WAY VALVE
26
SCREW SHUTTLE VALVE TO BRACKET
29
NUT HOOK TO BRACKET
29
NUT TWO-WAY VALVE TO BRACKET
32
SCREW PIPE CLAMP
32
SCREW , Replaced By: N304017008021
44
HOLLOW SCREW LINE CONNECTION
44
HOLLOW SCREW LINE CONNECTION
47
SEAL RING LINE CONNECTION
47
SEAL RING LINE CONNECTION
50
PLASTIC PIPE RISING PIPE 4X6 MM
50
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
53
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
56
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
59
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
62
SEAL RING LINE CONNECTION
62
SEAL RING LINE CONNECTION
65
HOLLOW SCREW HEATING CONNECTION
65
HOLLOW SCREW HEATING CONNECTION
68
UNION NUT BLEEDING, FROM IDENT NO. 5 033767,EXCEPT FOR 5 039977
71
GLAND BLEEDING, FROM IDENT NO. 5 033767,EXCEPT FOR 5 039977
74
SLEEVE LEAK LINE
125
SCREW (THROTTLE SCREW)
128
SEAL RING LINE CONNECTION
131
BRACKET LINE MOUNTING,4 411811
134
FITTING NEUTRAL POSITION 3/2-WAY VALVE, CONNECTION: "2"
137
SCREWM 6X10
140
SERRATED WASHER BRACKET TO CAB
143
NUT CLAMP TO BRACKET
146
SLEEVE LINE MOUNTING
149
GLAND LINE MOUNTING
152
UNION NUT LINE MOUNTING, Replaced By: N000000006521
155
CLAMP , Replaced By: N916016010211
158
SHEET METAL SCREW REFLECTOR TO BUMPER
161
SCREWM 6X12
164
SERRATED WASHER BRACKET TO CAB
167
NUT CLAMP TO BRACKET
170
BRACKET FUEL LINE TO BELL HOUSING
