Поз.
Артикул
Описание
5
VALVE (CHECK VALVE) VOSS
5
VALVE (CHECK VALVE) SCHAEFER
8
SEAL RING13.6X2 MM,TO 003 429 12 44,SCHAEFER
11
SEAL RING15.3X2.4 MM,TO 003 429 12 44,SCHAEFER
14
SEAL RINGTO 002 429 96 44,VOSS
17
THRUST WASHERTO 003 429 12 44,SCHAEFER
20
SEAL CONETO 003 429 12 44,SCHAEFER
23
VALVE TAPPETTO 002 429 96 44,VOSS
26
NUT CHECK VALVE TO AIR RESERVOIR
29
BRACKET HEAT SHIELD
32
SCREW EXHAUST PIPE TO SIDE MEMBER
35
NUT EXHAUST PIPE TO SIDE MEMBER
38
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
41
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
44
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
45
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
47
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
50
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
53
HOLLOW SCREW , Replaced By: N915036010108
56
SEAL RING FUEL LINE TO FEED PUMP
59
SEAL RING , Replaced By: N007603012121
62
FITTING LINE CONNECTION, Replaced By: N000000006446
65
SEAL RING LINE CONNECTION
